INTEGRAL GEOMETRY OF PAIRS OF PLANES

JULI `A CUF´I, EDUARDO GALLEGO AND AGUST´I REVENT ´OS

Abstract. We deal with integrals of invariant measures of pairs of planes in
euclidean spaceE^{3}as considered by Hug and Schneider. In this paper we express
some of these integrals in terms of functions of the visual angle of a convex
set. As a consequence of our results we evaluate the deficit in a Crofton-type
inequality due to Blashcke.

1. Introducction

The main goal of this paper is to study integrals of invariant measures with
respect to euclidean motions in the euclidean spaceE^{3}, extended to the set of pairs
of planes meeting a compact convex set. To carry out this objective we express
these integrals in terms of functions of the dihedral visual angle of the convex set
from a line and integrate them with respect to an invariant measure in the space
of lines.

The first known formula involving the visual angle of a convex set in the eu-
clidean planeE^{2} is Crofton’s formula given in [2]. Other results in this direction
were obtained by Hurwitz ([8]), Masotti ([10]) and others, in which the use of
Fourier series is the main tool. Recently the authors ([3], [4]) have dealt with a
general type of integral formulas from the point of view of Integral Geometry.

When trying to generalize these results to higher dimensions the role played by Fourier series in the case of the plane has to be replaced by the use of spherical harmonics. In this sense Theorem4.1plays an important role. After stating and proving this result in dimension 3 we were aware of the paper by Hug and Schnei- der [7] where a more general result in any dimension is proved. In fact the present paper can be considered in some sense as a complement to [7], the novelty been the introduction of the dihedral visual angle.

In Proposition3.1we give a characterization of invariant measures in the space of pairs of planes. These will be the kind of measures considered along the paper.

In section 4, using Hug-Schneider’s Theorem [7, p. 349], we give an expression for the integral of the sinus of the dihedral visual angle of pairs of planes meet- ing a given compact convex set K in terms of geometrical properties of K, see formula (4.3); also we characterize the compact convex sets of constant width in terms of invariant measures given by Legendre polynomials in Proposition4.3.

In section 5 we assign to any invariant measure on the space of pairs of planes an appropriate function of the dihedral visual angle of a given convex set. The

1991 Mathematics Subject Classification. Primary 52A15, Secondary 53C65.

Key words and phrases. Invariant measures, convex set, visual angle, constant width.

The authors were partially supported by grants 2017SGR358, 2017SGR1725 (Generalitat de Catalunya) and PGC2018-095998-B-100 (FEDER/MICINN).

1

integral of this function with respect to the measure on the space of lines gives the integral of the above measure extended to those planes meeting the convex set. This result is given in Theorem5.2. Then we relate this result to Blaschke’s work [1]. If K is a convex set of mean curvature M and area of its boundary F , Blaschke proves the formula

Z

G∩K=∅

(ω^{2}− sin^{2}ω) dG = 2M^{2}−π^{3}F
2

where ω = ω(G) is the dihedral visual angle of K from the line G. This equality
reveals the significance of the function of the visual angle ω^{2}− sin^{2}ω. One can
ask what role does it play the function ω− sin ω; this function, interpreting ω as
the visual angle in the plane is significant thanks to Crofton formula. In [1] the

inequality Z

G∩K=∅

(ω− sin ω) dG ≥ π

4(M^{2}− 2πF )

is stablished. Here we provide a simple formulation of the deficit in this inequality by means of Theorem5.4where it is proved that

Z

G∩K=∅

(ω− sin ω)dG = π

4(M^{2}− 2πF ) + π
X∞
n=1

Γ(n + 1/2)^{2}

Γ(n + 1)^{2} kπ2n(p)k^{2},
whith π2n(p) the projection of the support function p of K on the vector space of
spherical harmonics of degree 2n.

In section 6 we give a formulation of Theorem5.2in terms of Fourier series of the function of the visual angle assigned to an invariant measure. As a consequence one obtains that the integral of any invariant measure in the space of pairs of planes extended to those meeting a compact convex set K is an infinite linear combination of integrals of even powers of the sine of the visual angle of K. From this we exhibit in Proposition6.3a simple family of polynomial functions that are in some sense a basis for the integrals considered in Theorem 4.1. In fact every invariant integral can be written as an infinite linear combination of integrals with respect to the invariant measures given by those polynomial functions.

In section 7, motivated by the role played by the integrals of even powers of the sine of the visual angle of a compact set K we compute these integrals in terms of the expansion in spherical harmonics of the support function of K.

2. Preliminaries

Support function. The support function of a compact convex set K in the eu-
clidean spaceE^{3} is defined as

pK(u) = sup{hx, ui : x ∈ K}

for u belonging to the unit sphere S^{2}. If the origin O of E^{3} is an interior point
of K then the number pK(u) is the distance from the origin to the support plane
of K in the direction given by u. The width w of K in a direction u ∈ S^{2} is
w(u) = p_{K}(u) + p_{K}(−u).

From now on we will write p(u) = pK(u) and will assume that p(u) is of class C^{2};
in this case we shall say that the boundary of K, ∂K, is of classC^{2}.

Spherical harmonics. Let us recall that a spherical harmonic of order n on the
unit sphere S^{2} is the restriction to S^{2} of an harmonic homogeneous polynomial
of degree n. It is known that every continuous function on S^{2} can be uniformly
approximated by finite sums of spherical harmonics (see for instance [6]).

More precisely, the function p(u) can be written in terms of spherical harmonics as

p(u) = X∞ n=0

πn(p)(u), (2.1)

where π_{n}(p) is the projection of the support function p on the vector space of
spherical harmonics of degree n. An orthogonal basis of this space is given in
terms of the longitude θ and the colatitude ϕ in S^{2} by

{cos(jθ)(sin ϕ)^{j}P_{n}^{(j)}(cos ϕ), sin(jθ)(sin ϕ)^{j}P_{n}^{(j)}(cos ϕ) : 0≤ j ≤ n}

where Pn^{(j)} denotes the jth derivative of the nth Legendre polynomial P_{n}, see [6].

It can be seen that π_{0}(p) =W/2 = M/4π where W = 1/4πR

S^{2}w(u) du is the
mean width of K, and M is the mean curvature of K (cf. [6]). It is clear that
π_{0}(p) is invariant under euclidean motions and that π_{1}(p) is not. It is known that
π_{n}(p) is also invariant for every n6= 1 (cf. [12]).

As w(u) = p(u) + p(−u), one can easily check that K has constant width if and only if πn(p) = 0 for n6= 0 even.

We recall now the Funk-Hecke theorem which gives the value of the integral over the sphere of a given function multiplied by a spherical harmonic. We restrict ourselves to the case of dimension 3.

Theorem 2.1 (Funk-Hecke). If F : [−1, 1] −→ R is a bounded measurable function
and Y_{n} is a spherical harmonic of order n, then

Z

S^{2}

F (hu, vi)Yn(v)dσ(v) = λ_{n}Y_{n}(u), u∈ S^{2}
with

λn= 2π Z 1

−1

F (t)Pn(t) dt,
where P_{n} is the Legendre polynomial of degree n.

Measures in the space of planes. The space of planes A3,2 inE^{3} is a homo-
geneous space of the group of isometries ofE^{3}. It can also be considered as a line
bundle π :A3,2−→Gr(3, 2) where Gr(3, 2) is the Grassmannian of planes through
the origin inE^{3} and π(E) is the plane parallel to E through the origin. The fiber
on E_{0} ∈ Gr(3, 2) is identified with hE0i^{⊥}. Each plane E ∈ A3,2 is then uniquely
determined by the pair (π(E), E∩ hπ(E)i^{⊥}). Every pair (E0, p) ∈ Gr(3, 2) × R^{3}
determines an element E0+ p∈ A^{3,2}.

We shall also consider the space of affine lines A3,1 inE^{3}; it is a vector bundle
π : A3,1 −→ Gr(3, 1) where Gr(3, 1) is the Grassmannian of lines through the
origin and every affine line G⊂ E^{3}can be identified with (π(G), G∩ hπ(G)i^{⊥}) (see
for instance [9]).

Both the isometry group ofE^{3}and the isotropy group of a fixed plane E∈ A3,2

are unimodular groups; so the Haar measure of the group of isometries is projected into a isometry-invariant measure m onA3,2.

For a measurable set B⊂ A3,2 we consider m(B) =

Z

A3,2

χB(E)dE :=

Z

Gr(3,2)

Z

E_{0}^{⊥}

χB(E0+ p)dp

! dν

where χB is the characteristic function of B, dp denotes the ordinary Lebesgue
measure on E_{0}^{⊥} and dν a normalized isometry-invariant measure on Gr(3, 2) such
that ν(Gr(3, 2)) = 2π.

More generally, if f : A3,2 → R and ¯f : Gr(3, 2)× R^{3} → R are related by
f (E¯ _{0}, p) = f (E_{0}+ p) we have

Z

A3,2

f (E) dE :=

Z

Gr(3,2)

Z

E^{⊥}_{0}

f (E¯ 0, p)dp

! dν.

Notice that the only measures onA3,2 invariant under isometries are those of the form f (E)dE with f a constant function.

In a similar way one can define a normalized isometry-invariant measure onA3,1

that will be denoted by dG.

3. Invariant measures in the space of ordered pairs of planes
We consider measures in the spaceA3,2×A3,2of pairs of planes inE^{3}of the form
mf˜:= ˜f (E1, E2)dE1dE2. We want to study which functions ˜f give an isometry-
invariant measure, that is a measure mf˜ satisfying mf˜(B) = mf˜(gB) for every
euclidean motion g. For instance, it is known that for a given compact convex
set K one hasR

E∩K6=∅dE = M . So when ˜f (E_{1}, E_{2}) = 1 we have
Z

K∩Ei6=∅

dE1dE2= M^{2}= 4π^{2}W^{2},
(3.1)

where M andW are the mean curvature and the mean width of K, respectively.

Proposition 3.1. The measure given by ˜f (E_{1}, E_{2})dE_{1}dE_{2}inA3,2×A3,2is invari-
ant under isometries ofE^{3} if and only if ˜f (E_{1}, E_{2}) = f (hu1, u_{2}i) where π(Ei)^{⊥}=
huii, i = 1, 2 and f : [−1, 1] → R is an even measurable function.

Proof. Suppose that ˜f (E1, E2)dE1dE2is invariant. Using the representation of an
element E∈ A3,2 as a pair (π(E), p) where p = E∩ hπ(E)i^{⊥} we can write

f (E˜ 1, E2) = F (π(E1), p1; π(E2), p2)
for some F : (Gr(3, 2)× E^{3})^{2}→ R. For any translation τ it is

f (E˜ 1+ τ, E2+ τ ) = F (π(E1), p1+ τ ; π(E2), p2+ τ ).

Due to the invariance of ˜f (E1, E2)dE1dE2 we have

F (π(E1), p1+ τ ; π(E2), p2+ τ ) = F (π(E1), p1; π(E2), p2)

and so F is independent of p1and p2and we can write ˜f (E1, E2) = H(π(E1), π(E2)) for some function H on Gr(3, 2)× Gr(3, 2).

Given t∈ [−1, 1] consider (V, W ) ∈ Gr(3, 2)^{2} such that V = hvi^{⊥}, W =hwi^{⊥}
and t =hv, wi with v, w unit vectors. The function f(t) = H(V, W ) is well defined
since for any rotation θ we have that H(θV, θW ) = H(V, W ) and it is even. So it
is proved that there exists a measurable and even function f : [−1, 1] → R such
that

f (E˜ _{1}, E_{2}) = f (hu1, u_{2}i).

If ˜f is as above it is clear that ˜f (E_{1}, E_{2})dE_{1}dE_{2}gives rise to an isometry-invariant

measure.

4. Integral of functions of pairs of planes meeting a convex set Let K be a compact convex set in the euclidean space E3. According to equal- ity (3.1) it is a natural question to evaluate

Z

Ei∩K6=∅

f (E˜ 1, E2)dE1 dE2,

where ˜f (E_{1}, E_{2})dE_{1}dE_{2} is an isometry-invariant measure on A3,2 × A3,2. This
can be done in terms of the coefficients of the expansion of the support function
of K in spherical harmonics and the coefficients of the Legendre series of the
measurable even function f : [−1, 1] → R such that ˜f (E1, E2) = f (hu1, u2i) (see
Proposition3.1).

The following result is a special case, with a different notation, of Theorem 5 in [7]. However we include a proof of this particular case for reader’s convenience.

Theorem 4.1. Let K be a compact convex set with support function p given
in terms of spherical harmonics by (2.1). Let ˜f (E_{1}, E_{2})dE_{1}dE_{2} be an isometry-
invariant measure onA3,2× A3,2 and f : [−1, 1] → R an even measurable function
such that ˜f (E1, E2) = f (hu1, u2i) where π(Ei)^{⊥} =huii, i = 1, 2. Then

(4.1)

Z

Ei∩K6=∅

f (E˜ _{1}, E_{2})dE_{1}dE_{2}= λ0

4πM^{2}+
X∞
n evenn=2

λ_{n}kπn(p)k^{2},

where λn = 2πR1

−1f (t)Pn(t) dt with Pn the Legendre polynomial of degree n.

Proof. As ˜f (E1, E2) = f (hu^{1}, u2i) we have that
Z

Ei∩K6=∅

f (E˜ 1, E2)dE1 dE2= Z

Ei∩K6=∅

f (hu1, u2i)dE1 dE2. For a fixed plane E2 inA3,2 and writing dEi = dpi∧ dν one has

(4.2) Z

E1∩K6=∅

f (E˜ _{1}, E_{2})dE_{1}=
Z

Gr(3,2)

Z

hu1i

f (hu1, u_{2}i)dp1

! dν =

= Z

Gr(3,2)

f (hu1, u2i)(p(u1) + p(−u1))dν = Z

S^{2}

f (hu, u2i)p(u) du, where the last equality follows from the fact that f is even.

As p(u) =P_{∞}

n=0πn(p)(u) (cf. (2.1)) and using Funk-Hecke’s theorem we have

that Z

E1∩K6=∅

f (E˜ 1, E2)dE1= X∞ n=0

λnπn(p)(u2).

Notice that f being even one has λ_{n}= 0 for n odd. Now performing the integral
with respect E2 we have

Z

Ei∩K6=∅

f (E˜ _{1}, E_{2})dE_{1} dE_{2}=
X∞
n evenn=0

λ_{n}
Z

Gr(3,2)

Z

hu2i

π_{n}(p)(u_{2})dp_{2}

! dν =

= X∞ n evenn=0

λ_{n}
Z

S^{2}

π_{n}(p)(u)p(u) du =
X∞
n evenn=0

λ_{n}kπn(p)k^{2},

where we have used the fact that πn(p)(u) = πn(p)(−u) for n even. Taking into account that π0(p) = M/4π we have

kπ0(p)k^{2}= M^{2}

16π^{2}k1k^{2}= M^{2}
4π
and then

Z

Ei∩K6=∅

f (E˜ 1, E2)dE1dE2= λ_{0}
4πM^{2}+

X∞ n evenn=2

λnkπ^{n}(p)k^{2}.

Example 1. If f (t) = √

1− t^{2} then f (hu^{1}, u2i) = sin(θ^{12}) where 0 ≤ θ^{12} ≤ π
is the angle between de planes E_{1} and E_{2} (that is, cos θ_{12} = ±hu1, u_{2}i where
π(Ei)^{⊥} =huii, i = 1, 2). Applying Theorem4.1with the corresponding coefficients

λ2n = 2π Z 1

−1

f (t)P2n(t) =−Γ(n +^{1}_{2})Γ(n−^{1}_{2})
n!(n + 1)!

π

2, λ0= π^{2}, λ2n+1 = 0
(cf. [5], 7.132), one gets

(4.3) Z

Ei∩K6=∅

sin(θ12)dE1dE2= π

4M^{2}−π
2

X∞ n=1

Γ(n +^{1}_{2})Γ(n−^{1}_{2})

n!(n + 1)! kπ2n(p)k^{2}

! . In the particular case that f is a Legendre polynomial one obtains from Theo- rem4.1the following

Corollary 4.2. Let K be a compact convex set with support function p given in terms of spherical harmonics by (2.1). Then if Pn is the Legendre polynomial of even degree n, one has

Z

Ei∩K6=∅

P_{n}(hu1, u_{2}i) dE1dE_{2}= 4π

2n + 1kπn(p)k^{2}.
Proof. In this case λm= 0 for m6= n and λn= 4π

2n + 1.

Example 2. As the function f (t) = t^{2n} can be written in terms of Legendre poly-
nomials as t^{2n}=

Xn k=0

µn,kP2k(t) with

(4.4) µ_{n,k}= (4k + 1)Γ(2n + 1)√π
2^{2n+1}Γ(n− k + 1)Γ(n + k + 3/2)
(see [5], 8.922) we get the following consequence of Corollary4.2:

Z

Ei∩K6=∅hu^{1}, u2i^{2n}dE1dE2=
Xn
k=0

4π

4k + 1µ_{n,k}kπ2k(p)k^{2}
where µn,k are given by (4.4).

To end this section we analyze equality (4.1) when K is a convex set of constant width. As said this means that πn(p) = 0 for n6= 0 even.

Proposition 4.3. Let K be a compact convex set of constant width W and let f : [−1, 1] −→ R an even bounded measurable function. Then

Z

Ei∩K6=∅

f (hu1, u_{2}i) dE1dE_{2}= λ_{0}πW^{2},
(4.5)

with λ0 = 2πR1

−1f (t)dt. Moreover if the above equality holds when f (t) = P2n(t)
where P_{2n} is any Legendre polynomial of even degree 2n, n 6= 0 then K is of
constant width.

Proof. Since K is of constant width by (4.1) one gets Z

Ei∩K6=∅

f (hu^{1}, u2i) dE^{1}dE2= λ0

4πM^{2}

and remembering that M = 2πW the equality follows. If equality (4.5) holds for f (t) = Pn(t) with n even, n6= 0, and since the corresponding λ0 vanishes one has

Z

Ei∩K6=∅

P_{n}(hu1, u_{2}i) dE1dE_{2}= 0.

Therefore by Corollary 4.2it follows that kπn(p)k = 0 for every non zero n even

and K is of constant width.

5. Integrals of invariant measures in terms of the visual angle The aim of this section is to write the integral of a isometry-invariant measure over the pairs of planes meeting a convex set K, given in Theorem 4.1, as an integral of an appropriate function of the visual angle.

Let us precise what we mean by the angle of a plane about a straight line G and the visual angle of a convex set K from a line G not meeting K.

Definition 5.1.

1. Given a straight line G let (q; e1, e2) be a fixed affine orthonormal frame
in G^{⊥} with q ∈ G. For each plane E through G let u be the unit normal
vector to E pointing from the origin to it. Then the angle α associated
to E is the one given by u = cos(α)e1+ sin(α)e2.

2. The visual angle of a convex set K from a line G not meeting K is the
angle ω = ω(G), 0 ≤ ω ≤ π, between the half-planes E1, E_{2} through G
tangents to K.

If αi are the angles associated to Ei, i = 1, 2 then cos(π− ω) = cos(α2− α1) =hu1, u2i

where u1, u2 are the normal unit vectors to E1, E2 pointing from the origin, as- suming the origin inside K.

The measure dE_{1}dE_{2} in the space A3,2× A3,2 of pairs of planes in E^{3} can be
written according to Santal´o (cf. [11], section II.12.6) as

dE1dE2= sin^{2}(α2− α1) dα1dα2dG.

(5.1)

Then we can prove the following

Theorem 5.2. Let K be a compact convex set and let f : [−1, 1] −→ R be an even
continuous function. Let H be the C^{2} function on [−π, π] satisfying

H^{00}(x) = f (cos(x)) sin^{2}(x), −π ≤ x ≤ π, H(0) = H^{0}(0) = 0.

Then (5.2)

Z

Ei∩K6=∅

f (hu1, u_{2}i) dE1dE_{2}= πH(π)F + 2
Z

G∩K=∅

H(ω) dG,

where u_{i} are normal unit vectors to the planes E_{i}, ω = ω(G) is the visual angle
from the line G and F is the area of the boundary of K.

Proof. Let G = q +hui with u a unit director vector such that K ∩ G = ∅.

Let E_{i}, i = 1, 2 be the supporting planes of K through G. Take now an affine
orthonormal frame {q; e1, e2, u} in E^{3} such that E1 = q +he1, ui. Every plane E
through G can be written as E = q +hv^{α}, ui where v^{α} = cos αe1+ sin αe2 with
α ∈ [0, π) and the planes E intersecting K correspond to angles α ∈ [0, ω(G)].

Then using (5.1) one has Z

Ei∩K6=∅

f (hu1, u_{2}i) dE1dE_{2}=

= Z

G∩K=∅

Z ω 0

Z ω 0

H^{00}(α2− α^{1}) dα1dα2dG +
+

Z

G∩K6=∅

Z π 0

Z π 0

H^{00}(α2− α1) dα1dα2dG.

Evaluating the inner integrals and taking into account that R

G∩K6=∅dG = ^{π}_{2}F it
follows

Z

Ei∩K6=∅

f (hu1, u_{2}i) dE1dE_{2}=

= 1

2π(H(π) + H(−π))F + Z

G∩K=∅

(H(ω) + H(−ω)) dG.

Since H(0) = H^{0}(0) = 0 and H^{00}(x) = H^{00}(−x) it is easy to see that H(x) = H(−x)

and the result follows.

Example 3. Consider f (t) = 1 then H(x) = (x^{2}− sin^{2}x)/4 and
M^{2}=

Z

Ei∩K6=∅

dE1dE2= 1

4π^{3}F +1
2

Z

G∩K=∅

(ω^{2}− sin^{2}ω) dG,
(5.3)

which gives the well known Blaschke’s formula (cf. [1]) Example 4. Let f (t) =√

1− t^{2} be the function considered in Example1. In this
case the corresponding function H such that

H^{00}(x) = f (cos(x)) sin^{2}(x) =| sin^{3}(x)|
is given by

H(x) = 2

3(|x| − | sin x|) −1

9| sin^{3}x|.

Now, since ω∈ [0, π], Theorem 5.2and equality (4.3) leads to Z

G∩K=∅

ω− sin ω − 1
3!sin^{3}ω

dG =

= π 3M^{2}
16 −1

2πF −3 8

X∞ n=1

Γ(n +^{1}_{2})Γ(n−^{1}2)

n!(n + 1)! kπ2n(p)k^{2}

!
.
Example 5. Taking now f (t) = t^{2}, one gets H(x) = 1/16(x^{2} − sin^{2}x cos^{2}x) =
1/16(x^{2}−sin^{2}x+sin^{4}x). According Exemple2, Theorem5.2and Blaschke formula
one gets

(5.4) 1

3M^{2}+8π

15kπ2(p)k^{2}=
Z

Ei∩K6=∅hu1, u2i^{2}dE1dE2=

= 1

4M^{2}+1
8

Z

G∩K=∅

sin^{4}ω dG,

and so Z

G∩K=∅

sin^{4}ω dG = 2

3M^{2}+64π

15 kπ2(p)k^{2}.
Notice that in the case that K has constant width one obtains

Z

G∩K=∅

sin^{4}ω dG = 2
3M^{2}.
More generally if f (t) = t^{2n} we have the following

Proposition 5.3. Let K be a compact convex set with mean curvature M. Then one has

(5.5) Z

Ei∩K6=∅hu^{1}, u2i^{2n}dE1dE2=−4A^{(n)}1 M^{2}+ 2

n+1X

r=2

A^{(n)}_{r}
Z

G∩K=∅

sin^{2r}ω dG,
where

A^{(n)}_{r} = (−1)^{r} _{r−1}^{n}

4r^{2} ^{3}F2(1, r + 1/2, r− n − 1; r, r + 1; 1), r = 1, . . . , n + 1.

We recall that_{3}F_{2} is the hypergeometric function given by

3F2(a1, a2, a3; b1, b2; z) = X∞ n=0

(a_{1})_{n}(a_{2})_{n}(a_{3})_{n}
(b_{1})_{n}(b_{2})_{n}

z^{n}
n!

with (a)_{n}= Γ(a + n)/Γ(a) is the Pochhammer symbol.

The integral in the left-hand side of (5.5) was calculated in Exemple2in terms of the expansion in spherical harmonics of the support function of K.

Proof. We will apply Theorem 5.2for f (t) = t^{2n}, that is H^{00}(x) = cos^{2n}x sin^{2}x.

We search the corresponding H(x). Le us write
H^{00}(x) =

Xn k=0

n k

(−1)^{k}sin^{2(k+1)}x.

Integrating twice and using formula 2.511(2) in [5] we get H(x) = 1

4(x^{2}− sin^{2}x)+

+ Xn k=1

n k

(−1)^{k}

"

α_{k}x^{2}

2 − 1

2(k + 1)

sin^{2(k+1)}x
2(k + 1) +

Xk r=1

β_{r}^{(k)}sin^{2(k}^{−r+1)}x
2(k− r + 1)

!#

, with

αk= Γ(k + 3/2)

Γ(k + 2) , β_{r}^{(k)}= Γ(k− r + 1)Γ(k + 3/2)
Γ(k + 1)Γ(k− r + 3/2).
This provides for H(x) an expression of the type

H(x) = A^{(n)}_{0} x^{2}+ A^{(n)}_{1} sin^{2}x +· · · + A^{(n)}n+1sin^{2(n+1)}x.

Let us find now the values on A^{(n)}r . Beginning with A^{(n)}_{0} one gets
A^{(n)}_{0} =

2n n

2^{2(n+1)}.
For r > 0 one has

A^{(n)}_{r} = 1
4

Xn k=r−1

n k

(−1)^{k+1}
k + 1

β_{k}^{(k)}_{−r+1}

r , r = 1, . . . , n + 1, or in a more compact form

A^{(n)}_{r} = (−1)^{r} _{r}_{−1}^{n}

4r^{2} ^{3}F2(1, r + 1/2, r− n − 1; r, r + 1; 1), r = 1, . . . , n + 1.

One easily sees that A^{(n)}_{0} =−A^{(n)}1 an so
(5.6) H(x) = A^{(n)}_{0} (x^{2}− sin^{2}x) +

n+1X

r=2

A^{(n)}_{r} sin^{2r}x.

Finally Theorem5.2and Blaschke identity (5.3) give the result.
5.1. Crofton’s formula in the space. Blaschke’s formula (5.3) reveals the sig-
nificance of the function of the visual angle ω^{2}− sin^{2}ω. One can ask what role
the function ω− sin ω plays; this function, interpreting ω as the visual angle in the
plane, is significant thanks to Crofton’s formulaR

P /∈K(ω− sin ω)dP = L^{2}/2− πF ,
where K is a compact convex set in the plane with area F and length of its
boundary L (see [11]).

In [1, p. 85] Blaschke shows that (5.7)

Z

G∩K=∅

(ω− sin ω)dG = 1 4

Z

u∈S^{2}

L^{2}_{u}du−π^{2}
2 F,
where Lu is the length of the boundary of the projection of K onhui^{⊥}.

It can be easily seen that R

u∈S^{2}Ludu = 2πM and from this equality, applying
Schwarz’s inequality, one gets

(5.8)

Z

u∈S^{2}

L^{2}_{u}du≥ πM^{2}.
Introducing (5.8) into (5.7) one obtains

(5.9)

Z

G∩K=∅

(ω− sin ω)dG ≥ π

4(M^{2}− 2πF ).

As a consequence of Theorem 5.2we can now evaluate the deficit in both in- equalities (5.8) and (5.9).

Theorem 5.4. Let K be a compact convex set with support function p, area of
its boundary F and mean curvature M . Let Lu be the length of the boundary of
the projection of K on hui^{⊥} and let ω = ω(G) be the visual angle of K from the
line G. Then

i) Z

u∈S^{2}

L^{2}_{u}du = πM^{2}+ 4π
X∞
n=1

Γ(n + 1/2)^{2}

Γ(n + 1)^{2} kπ2n(p)k^{2},
ii)

Z

G∩K=∅

(ω− sin ω)dG = π

4(M^{2}− 2πF ) + π
X∞
n=1

Γ(n + 1/2)^{2}

Γ(n + 1)^{2} kπ2n(p)k^{2}.
Moreover equality holds both in (5.8) and (5.9) if and only if K is of constant
width.

Proof. We consider f (t) = 1/√

1− t^{2}. For this function the corresponding H in
Theorem5.2is H(x) =|x|−| sin x|. Applying equality (5.2) and Theorem4.1with
the corresponding λ2n’s given by

λ2n= 2π Z 1

−1

f (t)P2n(t)dt = 2πΓ(n + 1/2)^{2}
Γ(n + 1)^{2} ,

(cf. [5], 7.226), item ii) follows. Equality i) is a consequence of ii) and (5.7).

The statement about equality in (5.8) and (5.9) is a consequence of the fact that K is of constant width if and only if π2n(p) = 0 for n6= 0.

6. A formulation with Fourier series

In this section we give an alternative formulation of Theorem 5.2 in terms of
Fourier coefficients of the function H^{00}(x). Since f is even one has that H^{00}(x) =
f (cos(x)) sin^{2}(x) is an even π-periodic function. Let

(6.1) H^{00}(x) = 1

2a_{0}+X

n≥1

a_{2n}cos(2nx)

be the Fourier expansion of H^{00}(x). Integrating twice and taking into account that
H(0) = H^{0}(0) = 0 one obtains

H(x) = a_{0}

4x^{2}+X

n≥1

a_{2n}

4n^{2}(1− cos(2nx)).

(6.2)

Using this expression of the function H, Theorem5.2can be written as

Proposition 6.1. Let K be a compact convex set and let f : [−1, 1] −→ R be an
even continuous function. Let H be theC^{2} function on [−π, π] satisfying

H^{00}(x) = f (cos(x)) sin^{2}(x), −π ≤ x ≤ π, H(0) = H^{0}(0) = 0.

(6.3)

If H(x) is given by (6.2) then (6.4)

Z

Ei∩K6=∅

f (hu1, u_{2}i) dE1dE_{2}=

= a_{0}

4π^{3}F +1
2

Z

G∩K=∅

a0ω^{2}+X

n≥1

a_{2n}

n^{2} (1− cos(2nω))

dG,

where u_{i} are normal vectors to the planes E_{i}, the visual angle from the line G is
ω and F denotes the area of the boundary of K.

The right hand side of (6.4) can be written as a linear combination of integrals of even powers of sin ω. For this purpose we will use Blaschke formula (5.3) and the known equality

(6.5) cos 2nx = Xn m=0

α_{n,m}sin^{2m}x with α_{n,m}= (−1)^{m}n 2^{2m}(n + m− 1)!

(2m)!(n− m)! ,
which follows easily from the equality cos(2nx) = (−1)^{n}T_{2n}(sin x) where T_{2n} is
Chebyshev’s polynomial of degree 2n. We can state

Proposition 6.2. Let K be a compact convex set and let f : [−1, 1] −→ R be an
even continuous function. Let H be theC^{2} function on [−π, π] satisfying

H^{00}(x) = f (cos(x)) sin^{2}(x), −π ≤ x ≤ π, H(0) = H^{0}(0) = 0.

If H(x) is given by (6.2) then (6.6)

Z

Ei∩K6=∅

f (hu1, u_{2}i) dE1dE_{2}=

= a_{0}M^{2}−1
2

X∞ m=2

X∞ n=m

a2n

n^{2}α_{n,m}
Z

G∩K=∅

sin^{2m}ω dG

!
,
where u_{i} are normal vectors to the planes E_{i}, the visual angle from the line G is ω,
F denotes the area of the boundary of K, the coefficients α_{n,m} are given by (6.5)
and the coefficients a2n by (6.1).

Proof. Using (6.5) the right hand side of (6.4) is written as
a_{0}π^{3}

4 F +1 2

Z

G∩K=∅

a0ω^{2}−

X∞ n=1

a_{2n}

n^{2}αn,1sin^{2}ω−
X∞
n=2

a_{2n}
n^{2}

Xn m=2

αn,msin^{2m}ω

dG =

= a0π^{3}
4 F +1

2 Z

G∩K=∅

a_{0}(ω^{2}− sin^{2}ω)−
X∞
n=2

a2n

n^{2}
Xn
m=2

α_{n,m}sin^{2m}ω

dG
where we have used that α_{n,0} = 1, α_{n,1} = −2n^{2} and a_{0} = −2P_{∞}

n=1a_{2n} which
is a consequence of the fact that H^{00}(0) = 0. Using Blaschke formula (5.3) and

reordering the double sum the result follows.

6.1. A basis for the integrals of invariant measures. As a consequence of Proposition6.2we can exhibit a simple family of polynomial functions that are in some sense a basis for the integrals in Theorem4.1. Consider the polynomials

hm(t) = m(2mt^{2}− 1)(1 − t^{2})^{m}^{−2}, m > 1.

(6.7)

Then for H^{00}(x) = hm(cos(x)) sin^{2}(x) one easily checks that H(ω) = ^{1}_{2}sin^{2m}ω and
Theorem5.2applied to h_{m}(t) gives

Z

Ei∩K6=∅

h_{m}(hu1, u_{2}i) dE1dE_{2}=
Z

G∩K=∅

sin^{2m}ω dG,
that together with equation (6.6) leads to the following

Proposition 6.3. Under the same hypotheses and notation as in Proposition 6.2 one has

Z

Ei∩K6=∅

f (hu1, u_{2}i) dE1dE_{2}=

= a_{0}M^{2}−1
2

X∞ m=2

X∞ n=m

a2n

n^{2} α_{n,m}
Z

Ei∩K6=∅

h_{m}(hu1, u_{2}i) dE1dE_{2}

! , where the polynomials hmare given in (6.7).

So every invariant integral can be written as an infinite linear combination of the integrals of the invariant measures given by the polynomials hm.

7. Powers of sine function of the visual angle Equality (6.6) suggests to consider integrals of the form

Z

G∩K6=∅

sin^{2m}ω dG.

Integrals of the power of the sine of the visual angle ω for a compact convex set K in the plane were considered in [3] obtaining

Z

P6∈K

sin^{2m}ω dP = λ_{0}L^{2}+X

k≥2, even

λ_{k}c^{2}_{k},

for convenient λk and where ck depends on the support function of K. Applying
this formula to the projections Kuof a compact convex set K in the euclidean space
on the planehui^{⊥} and taking into account that dG = dP ∧ du and ωu(P ) = ω(G)
one gets

Z

G∩K=∅

sin^{2m}ω dG = 1
2

Z

u∈S^{2}

Z

P6∈Ku

sin^{2m}ωudP du =

=λ0

2 Z

u∈S^{2}

L^{2}_{u}du +X

k≥2, even

λk

2 Z

u∈S^{2}

c^{2}_{k,u}du.

The first integral in the right hand side was geometrically interpretated in Theo- rem5.4but the second one has not been handled.

A more direct way to deal with the integral of the power of the sine of the visual angle for a compact convex set K in the euclidean space is by means of our previous results. In fact, we have the following

Proposition 7.1. Let K be a compact convex set with support function p given in terms of spherical harmonics by (2.1) then

(7.1) Z

G∩K=∅

sin^{2m}ω dG = m√

π(m− 2)!

4Γ(m +^{1}_{2}) M^{2}+

mX−1 k=1

β_{2k}kπ2k(p)k^{2}, m > 1,
where M is the mean curvature of K and the β_{2k}’s are given by

(7.2) β2k= (−1)^{k+1}m(m− 2)!^{2}Γ(k + 1/2) (2m− 1)(2k − 1)(k + 1) + m
k!(m− k − 1)!Γ(m + k + 1/2) π.

Remark 7.2. When K is a convex set of constant width one haskπ2k(p)k^{2}= 0 and

so Z

G∩K=∅

sin^{2m}ω dG = m√π(m− 2)!

4Γ(m + ^{1}_{2}) M^{2}.
Proof. Comparing relations (4.1) and (5.2) we have

β0

4πM^{2}+
X∞
k=1

β_{2k}kπ2k(p)k^{2}= πH(π)F + 2
Z

G∩K=∅

H(ω) dG
where H^{00}(x) = f (cos x) sin^{2}x with H(0) = H^{0}(0) = 0 and β_{2k}= 2πR1

−1f (t)P_{2k}(t) dt.

As said above, the function H corresponding to the polynomials hmgiven in (6.7)

is H(ω) = ^{1}_{2}sin^{2m}ω. In this case we have that β2k = 0 for k > m− 1 because
hm(t) is a polynomial of degre 2(m− 1) and R1

−1hm(t)P2k(t) = 0 for k > m− 1.

In order to compute

β_{2k} = 2π
Z 1

−1

h_{m}(x)P_{2k}(x)dx

we first observe that, using a Computer algebra system (CAS) we get Z 1

−1

h_{m}(x)x^{2j}dx = m(4mj− 2j + 1)Γ(j + 1/2)Γ(m − 1)
2Γ(m + j + 1/2) .
(7.3)

Now, recalling the expression of the Legendre polynomials
P_{2k}(x) = 1

2^{2k}
Xk
r=0

(−1)^{r}

2k r

4k− 2r 2k

x^{2(k}^{−r)}
we have

Z 1

−1

h_{m}(x)P_{2k}(x)dx =

= mΓ(m− 1)
2^{2k+1}

Xk r=0

(−1)^{r}

2k r

4k− 2r 2k

Γ(k−r + 1/2)(4m(k−r)−2(k − r)+1) Γ(m + k− r + 1/2) , but this sum is computable, using again a CAS we have

Z 1

−1

hm(x)P2k(x)dx =

= 1

2^{2k+1}mΓ(m− 1)

Γ(m− 1)Γ(1/2 − 2k)Γ(k − 1/2)·

·

(m−1)(2k−1)

4k 2k

((4m−2)k+1)−2(2m−1)k(4k−1)

4k− 2 2k

(2m+2k−1)

·

· 1

2Γ(1/2− k)Γ(m − k)Γ(m + k + 1/2)

.
Simplifyng this expression and taking into account that Γ(1/2 + j)Γ(1/2− j) =
(−1)^{j}π we finally obtain

β2k = 2π Z 1

−1

hm(x)P2k(x)dx

= (−1)^{k+1}m(m− 2)!^{2}Γ(k + 1/2) (2m− 1)(2k − 1)(k + 1) + m
k!(m− k − 1)!Γ(m + k + 1/2) π.

References

[1] W. Blaschke. Vorlesungen uber Integralgeometrie. VEB Deutscher Verlag der Wissenschaften, Berlin, 3rd edition, 1955.

[2] M.W. Crofton. On the theory of local probability. Phil.Trans.R.Soc.Lond., 158:181–199, 1868.

[3] J. Cuf´ı, E. Gallego, and A. Revent´os. Integral geometry about the visual angle of a convex set. Rendiconti del Circolo Matematico di Palermo, 2019.

[4] J. Cuf´ı, E. Gallego, and A. Revent´os. On the integral formulas of Crofton and Hurwitz relative to the visual angle of a convex set. Mathematika, 65(4):874–896, 2019.

[5] I.S. Gradshteyn and I.M. Ryzhiz. Table of Integrals, Series and Products. Academic Press, seventh ed edition, 2007.

[6] H. Groemer. Geometric applications of Fourier series and spherical harmonics, volume 61 of Encyclopedia of Mathematics and its Applications. Cambridge University Press, Cambridge, 1996.

[7] D. Hug and R. Schneider. Integral geometry of pairs of hyperplanes or lines. Arch. Math.

(Basel), 115(3):339–351, 2020.

[8] A. Hurwitz. Sur quelques applications geometriques des s´eries de Fourier. Annales scien- tifiques de l’ ´E.N.S., 3`eme s´erie, 19:357–408, dec 1902.

[9] D.A. Klain and G.C. Rota. Introduction to Geometric Probability. Lezioni Lincee. Cambridge University Press, 1997.

[10] G. Masotti. La Geometria Integrale. Rend. Sem. Mat. Fis. Milano, 25:164–231 (1955), 1953–

54.

[11] L.A. Santal´o. Integral geometry and geometric probability. Cambridge Mathematical Library.

Cambridge University Press, Cambridge, second edition, 2004. With a foreword by Mark Kac.

[12] R. Schneider. Convex bodies: the Brunn-Minkowski theory (second expanded edition). Cam- bridge University Press, 2013.

Departament de Matem`atiques, Universitat Aut`onoma de Barcelona, 08193 Bel- laterra, Barcelona, Catalonia

E-mail address: jcufi@mat.uab.cat, egallego@mat.uab.cat, agusti@mat.uab.cat
