Why ?
Why ?
Period [1980-1984]
• Dr. F. J. Serón made its Ph. D. working in the geophysical problem of Love earthquake waves propagation. His supervisor was Dr. J. I. Badal.
• Features
• 2D problem
• Strategy: Modal analysis based on the finite element method
• VAX11-780 [SISD] scalar computer
Why ?
Period [1985-1990]
• Dr. F. J. Serón works with Dr. J. I. Badal in the problem of the analysis of traveltime and amplitude of full elastic wave propagation in 2D oil and gas reservoirs.
• Features
• 2D problem
• Strategy: finite element method which produces very big size linear equations with a huge number of right-hand side vectors
• IBM 3090 VF (Vector Facility) [SIMD] vector computer
Why ?
• Period [1991-2000] Dr. F. J. Sabadell made its PH. D. working in the problem of the analysis of traveltime and amplitude of full elastic wave propagation in 2D oil and gas reservoirs. His supervisors were Dr. F. J. Serón and Dr. J. I. Badal
– Characteristiques of the work
• 2D and 3D problem
• Strategy Based on Domain Decomposition + analysis based on the finite element method
• Cluster of workstation [MIMD] and Cray T3D
Why ?
Period [1991 - …]
• Dr. F. J. Serón works in the Computer Graphics rendering problem with different members of the GIGA group, specially with Dr. J. A. Magallon
– Standard approximation
• 3D problem
• Strategy Based on heuristic approximation of the rendering equation
• Real time
• GPU´s [SIMD]
– Simulation of the real phenomena
• 3D problem
• Strategy Based on Monte-Carlo approximation of the rendering equation
• No real time
• Cluster of computers with GPU´s [SIMD + MIMD]
Index
