THERMOECONOMIC AND ENVIRONMENTAL OPTIMIZATION OF POLYGENERATION SYSTEMS
FOR SMALL-SCALE RESIDENTIAL BUILDINGS INTEGRATING THERMAL AND ELECTRIC ENERGY
STORAGE, RENEWABLE ENERGY AND LEGAL RESTRICTIONS.
Director/es
Serra de Renobales, Luis María Autor
2021
UNIVERSIDAD DE ZARAGOZA
Escuela de Doctorado
Thermoeconomic and environmental optimization of polygeneration systems
for small-scale residential buildings integrating thermal and electric energy
storage, renewable energy and legal restrictions
Author
Edwin Samir Pinto Maquilon
Advisor
Prof. Luis Mar´ıa Serra de Renobales
Ph.D. Program in Mechanical Engineering Universidad de Zaragoza
2021
Pa’ lante es pa’ all´a!
eπ
technical and scientific aspects, it is a fact that the achievement of a PhD is a merit of the effort and sometimes the sacrifices of a person. However, it is also a fact that to achieve the goal, the PhD student (he/she) has been definitely supported by a group of persons who in different ways helped him/her along the road. My case is not an exception, because I have to acknowledge the support of many important people along my PhD road. First of all, the support of my advisor Luis M. Serra for his enthusiasm and patience but specially for believe in me. Although many people must be acknowledged, I consider that GITSE gathers most of them. In particular, I would like to highlight the unmensurable support of Ana L´azaro and Jose Mar´ıa Marin.
People are the most important; however, the financial aspects also played an important role in my PhD. Therefore, first of all I acknowledge to the mobility program for Latin-Americans offered by Unizar-Santander Universities, since it allowed me to come to Zaragoza for study my PhD. Besides, this work was de- veloped in the frame of the research project ENE2017-87711-R, partially funded by the Spanish Government (Energy Program), the Government of Aragon (Ref:
T55-17R), Spain, and the EU Social Fund (FEDER Program 2014-2020 ”Build- ing Europe from Aragon”) which must be also gratefully acknowledged.
I would like to extend my acknowledge to the Campus Iberus and the EU’s Erasmus+ programme for allowing me to carry out my research stay in the LaTep-Universit´e de Pau. Likewise, thanks to Latep group specially to Erwin Franquet for hosting me.
Thanks to Dr. Omar Guerra for his help and advices about optimization issues. I would like to acknowledge his important scientific support along my thesis.
Last but not least, my very special acknowledge is to my wife Maryluz, for showing me her love through her unconditional support in every moment and encouraging me to go ahead.
quien agradecer, y como es cuesti´on de sentimientos, la mejor forma de expre- sarlos es en mi lengua materna. Esta ´ultima palabra da pie a la primera persona a agradecer, ayer, hoy y siempre. Y es que... yo quisiera preguntar cual cari˜no es el m´as grande del mundo, sin duda nadie se equivocar´a y s´e que todos dir´an, que es una bella mujer, una bendici´on de Dios, es mi mam´a♥♥∞n. Ella me ense˜n´o con su ejemplo a no rendirme ante las adversidades, porque pa’ lante es pa’ all´a, pa’ atr´as ni pa’ coger impulso.
A Maryluz♥♥ mi novia, mi mujer, mi amiga ∞...n con quien he vivido las experiencias m´as significativas de mi vida, quien me ha hecho ver el mundo m´as boniton. Llegar a este punto es la suma de muchas decisiones, la mayor´ıa entorno a ella, gracias por la traves´ıa y tu apoyo para alcanzar este logro.
GITSE, grupo de ingenieros t´ermicos soltando exerg´ıa, cari˜no, entusiasmo, alegr´ıa, apoyo...en fin, a todos y cada uno, los que est´an y ya no est´an, gracias por acompa˜narme en este camino. Y claro, especialmente a mi equipo de running, Anik? y el entrenadorΦ, que indudablemente me impulsaron a seguir adelante en el 2017 y me ayudaron a alcanzar la meta, y a´un m´as, me ayudaron a ver las cosas realmente importantes que van m´as all´a del PhD. A la comandante∗ por su sonrisa y disposici´on, un gusto ser su secre. A Luis\, por continuar conmigo adelante y confiar en m´ı...por ser humano...mil y mil gracias.
Quiero agradecer tambi´en al Dr. Omar Guerra (Optimizerman) por su gran ayuda para abordar la optimizaci´on a lo largo de mi tesis y al Dr. Said Pert´uz (el genio) por sus brillantes aportes en diferentes aspectos t´ecnico-cient´ıficos, pero ante todo gracias a ambos por su colaboraci´on desinteresada siempre que estuvo en sus manos.
Y es que... aquel que nunca ha estado ausente no ha sufrido un guayabo, hay cosas que hasta que no se viven no se saben...♥n As´ı, finalmente, agradezco a familiares y amigos, en especial a mi hermanita Dra. Julieth (Doctora de las que cura) y mi t´ıa Meche (mi segunda madre) por sus oraciones y buenos deseos en todo momento al igual que mi a madrina-suegra, por ser quien es, gracias.
Insisto, no hay como agradecer expl´ıcitamente a tantas personas que de una u otra forma me han ayudado, pero afortunadamente a cada uno le he agradecido personalmente a lo largo de este camino llamado doctorado.
Merci Beaucoup!
eπ
tion and 17% of the greenhouse gas emissions, plays a key role in the action to combat climate change. In this sense, polygeneration systems could be consid- ered a suitable alternative to attend the energy demands of residential buildings since they enable an efficient use of natural resources with a low environmental impact. This thesis developed a Mixed Integer Linear Programming (MILP) model to research these kind of systems in a systematic way to integrate re- newable energy such as solar and wind energy with thermal and electric energy storage, considering commercial equipment for small-medium scale residential buildings, taking into account both economic and environmental aspects for the optimal design of such systems. The research starts from the suitable way to address the optimization process focused on the selection of the method to se- lect representative days. Through the comparison of different methods, it was demonstrated that its right selection strongly depends on the variability of the time series involved in the analysed system. Besides, a new method was devel- oped in order to improve the results of the optimization process. The developed MILP model was applied to study the feasibility of residential buildings as a microgrid. This innovative approach was found profitable with respect to the current conventional energy systems but it is necessary the application of feed-in tariff schemes or allowing the sale of electricity at reasonable price in order to make them competitive. Further, a thermoeconomic analysis was carried out to evaluate synergies between the components of the energy system. It was shown the importance of considering both thermal and electrical parts in the design of energy systems, highlighting the role of heat pumps and energy storage as key technologies, to achieve more cost-effective and sustainable solutions. Fi- nally, the recent Spanish self-consumption regulations were applied to evaluate its impact on the design of energy systems. Moreover, through the application of multiobjective optimization and the analysis of different trade-off solutions was evaluated if this regulation aligned with European and international goals to combat climate change, and how it could be addressed in order to promote the design of affordable sustainable energy supply systems for the residential buildings. The obtained results suggest to act on the self-consumption regula- tion in order to achieve more significant reduction of greenhouse gas emissions.
Overall, this thesis provided methodologies and useful insights for the design of sustainable energy systems for residential buildings.
17% de emisiones de gases de efecto invernadero aproximadamente, desempe˜na un papel clave para combatir el cambio clim´atico. Por esto, el uso de sistemas de poligeneraci´on resulta una alternativa apropiada para cubrir las demandas energ´eticas de los edificios, ya que permiten un uso eficiente de los recursos naturales con un bajo impacto ambiental. En este sentido, esta tesis ha desar- rollado un modelo de programaci´on lineal entera mixta (MILP) para investigar estos sistemas de forma sistem´atica, integrando tecnolog´ıas renovables, como la solar y e´olica, con almacenamiento de energ´ıa t´ermica y el´ectrica, considerando equipos comerciales, teniendo en cuenta aspectos econ´omicos y ambientales en el dise˜no. La investigaci´on comienza por la forma de abordar el proceso de optimizaci´on, partiendo por la elecci´on del m´etodo para seleccionar d´ıas rep- resentativos. Comparando diferentes m´etodos, se demuestra que su idoneidad depende en gran medida de la variabilidad de las series temporales involucradas en el sistema analizado. Adem´as, se ha desarrollado un nuevo m´etodo que mejora los resultados del proceso de optimizaci´on. Por otro lado, se ha estudi- ado la viabilidad del uso de edificios residenciales como microrred. El estudio muestra que resultan rentables con respecto a los sistemas energ´eticos conven- cionales actuales, pero es necesario la aplicaci´on de incentivos o permitir la venta de electricidad a un precio razonable para que sean competitivos. Adi- cionalmente, se han estudiado e identificado sinergias entre los componentes del sistema energ´etico gracias al desarrollo de un modelo termoecon´omico, que muestran la importancia de abordar el dise˜no de los sistemas energ´eticos con- siderando conjuntamente tecnolog´ıas t´ermicas y el´ectricas, destacando la bomba de calor y los acumuladores de energ´ıa como tecnolog´ıas claves para lograr solu- ciones m´as econ´omicas y sostenibles. Finalmente, se han aplicado las ´ultimas regulaciones espa˜nolas de autoconsumo para evaluar su impacto econ´omico y ambiental en el dise˜no de sistemas energ´eticos. Adem´as, a trav´es de la apli- caci´on de la optimizaci´on multiobjetivo, se analiz´o si la reciente regulaci´on de autoconsumo se ajusta a las metas europeas e internacionales para combatir el cambio clim´atico. Asimismo, se estudia como podr´ıa abordarse la regulaci´on para promover el desarrollo de sistemas energ´eticos sostenibles para el sector residencial. Los resultados sugieren actuar sobre la regulaci´on de autoconsumo para reducir el impacto ambiental de forma efectiva. En general, esta tesis proporciona metodolog´ıas e ideas ´utiles para el dise˜no de sistemas energ´eticos sostenibles capaces de cubrir las demandas de energ´ıa de los edificios residen- ciales.
