Detecting moisture transport pathways to

the subtropical North Atlantic free

troposphere using paired H

₂

O-

δ

D in situ

measurements

Y. González1,2, M. Schneider3, C. Dyroff3, S. Rodríguez2, E. Christner3, O. E. García2, E. Cuevas2, J. J. Bustos2, R. Ramos2, C. Guirado-Fuentes2, S. Barthlott3, A. Wiegele3, and E. Sepúlveda2

1

Sieltec Canarias, S. L., Hábitat 2, 38204, San Cristóbal de La Laguna, Santa Cruz de Tenerife, Islas Canarias, Spain

2

Izaña Atmospheric Research Centre (IARC), Agencia Estatal de Meteorología (AEMET), Santa Cruz de Tenerife, Islas Canarias, Spain

3

Institute of Meteorology and Climate Research (IMK-ASF), Karlsruhe Institute of Technology (KIT), Karlsruhe, Germany

Received: 13 August 2015 – Accepted: 14 September 2015 – Published: 8 October 2015

Correspondence to: Y. González ([email protected])
