Crysfire.rtf Robin Shirley
V4.06 2 August 2002
User Manual
The Crysfire 2002 System for Automatic Powder Indexing
A Powder-indexing wizard in the form of a family of DOS scripts and programs for running indexing programs automatically
(including scripts for running from Qdat data file formats)
[Formatted for a Postscript printer in 10pt Times New Roman, and saved in Rich Text Format by MS Word as Crysfire.rtf]
1. Introduction to Crysfire 2002 and its New Features
One of the barriers to the current renaissance in ab initio structure determination from powder diffraction is the stubborn fact that, before structural work can be done on a material that is only available in powder form, its unit cell must be determined.
Unless the powder pattern can be indexed, the intensity associated with each reflection cannot be assigned to its location in reciprocal space, and further progress is impossible. With recent advances in methods for structure solution from powders, and especially in Rietveld refinement, this initial indexing stage is increasingly the main bottleneck in determining powder structures.
Though the unit cell completely determines the powder pattern (with intensities, instrumental factors, etc.), this is not logically reversible, since we can only resolve a relatively small, degraded and partly overlapping portion of the pattern that lies near the origin of reciprocal space. Powder indexing involves a complex process of induction that is far beyond manual methods in all but the simplest cases. Fortunately, there exist powerful and mature indexing programs, with intelligent front-ends and expert systems to assist the non-specialist in using them.
One of the most widely used of these is Crysfire. Despite its relatively unsophisticated interface, Crysfire continues to bring an unparalleled range of heavy-duty indexing software to non-specialist users. Eight programs contributed by various indexing specialists were included in its August 2000 release, including some not readily available elsewhere, plus a large toolbox of support facilities.
One of the central features was the generation of a log-file and a cumulative summary file for each dataset, which builds up as the investigation progresses, and shows a line-per-solution summary of each trial cell found by the various programs, sorted into descending order of lines indexed and figure of merit.
However, the Crysfire 2000 core was up against compiler-address-space limits. This new release, Crysfire 2002, has required a port of the core to a different language (Turbo Pascal, with the intention of migrating in due course to Delphi under MS Windows and Kylix under Linux), giving a largely rewritten version that has been completely revised internally and contains four times as many bytes of source code.
Crysfire 2000 users will find that the front-end interface largely remains familiar (since ability to reproduce the output from the previous version was used as a criterion of correctness), but the new Crysfire is now a close-coupled system, faster, more robust and easier to use. Nothing has been lost and there are several powerful new facilities.
All facilities can now be run directly from the main command menu, including programs that previously would only run as standalones. Another new feature is that on restarting Crysfire in a particular data directory, the most recently used dataset will automatically reload.
The online help has been redesigned and extended, supported by a clearer and more comprehensive manual (twice the size of its predecessor). All documentation for Crysfire and its supported indexing programs can now be viewed directly from the Crysfire command menu using new VM (View Manual) and VF (View File) commands.
Athlon PC, under Windows 95 or later. Nevertheless, it will still get there eventually on any PC that meets its very basic requirements (640K RAM, a hard disk of some sort and DOS 5 or later).
An obvious change, and hopefully an improvement, is the new IN (=index) command, which launches indexing programs directly (including Mmap - see below), automatically reloading the current dataset on returning (this cycle was previously a little clumsy and required several user commands).
All previous indexing programs are supported (often with considerable improvements), plus a completely new program Mmap, which can be used both for ab initio indexing and for topographical scans of solution space, since it generates a visual colour- contoured map of the hills and valleys of figure of merit plotted against lattice parameters.
For example, consider the case of the figure-of-merit surface surrounding a trial solution for a triclinic biological material, made more difficult to index by a dominant zone and very small particle size (producing some line-broadening). The dominant zone generates numerous mathematically-possible solutions, many of which might be plausible if the only criterion were refined figure of merit.
Section C: alpha* [Q(D)] across (77 to 73), beta* [Q(E)] down (82 to 80) 82.0 5 5 5 5 5 6 5 5 5 5 5 5 5 5 5 6 5 5 5 5 5 5 5 5 5 5 4 4 4 4 4 81.9 4 5 5 5 5 6 6 5 5 5 5 5 6 6 6 6 6 6 6 6 6 5 5 5 5 5 5 4 4 4 4 81.8 4 5 5 5 5 6 6 6 6 5 5 6 6 6 6 7 7 6 6 6 6 6 5 5 5 5 5 5 4 5 5 81.7 5 5 5 5 5 5 6 6 6 6 6 6 6 7 7 7 7 7 6 6 6 6 6 5 5 5 5 5 5 5 5 81.6 4 5 5 5 5 5 6 6 6 6 6 6 7 7 8 8 8 7 6 6 6 6 6 6 5 5 5 5 5 5 5 81.5 4 5 5 5 5 5 6 6 6 6 7 7 7 8 9 9 9 8 7 7 7 7 6 6 6 5 5 5 5 5 5 81.4 4 4 5 5 5 5 6 7 7 6 7 8 8 91010 9 8 7 7 7 7 7 6 6 6 5 5 5 5 6 81.3 4 4 4 5 5 5 6 7 7 7 7 8 910101110 9 8 7 7 7 7 6 6 6 5 5 6 6 6 81.2 4 4 4 5 5 5 6 6 7 7 8 8101112131210 8 7 7 7 7 7 6 6 6 6 6 6 6 81.1 4 4 4 5 5 5 5 6 7 7 8 9101215161311 9 8 7 7 7 7 6 6 6 6 6 6 7 81.0 4 4 4 5 5 5 5 6 7 7 8 910121621161210 8 7 7 7 7 7 6 6 6 7 7 7 80.9 4 4 4 5 5 5 5 6 7 7 8 8 9111317171310 8 7 7 7 7 7 6 6 7 7 7 7 80.8 4 4 4 4 5 5 5 5 6 7 7 8 8101112131311 9 8 7 7 7 6 6 6 7 7 7 7 80.7 4 4 4 4 5 5 5 5 6 6 7 8 8 91011111010 9 8 8 7 7 6 6 7 7 7 7 7 80.6 4 5 4 5 5 5 5 5 5 6 6 7 8 8 8 9 9 9 8 9 8 7 7 7 7 6 7 7 7 7 6 80.5 4 4 5 5 5 5 5 5 5 6 6 7 8 8 8 8 8 8 7 7 7 7 7 7 7 7 7 7 7 7 6 80.4 4 4 4 5 5 5 5 5 5 5 6 6 7 7 7 8 7 7 7 6 6 6 7 7 7 7 7 8 7 7 6 80.3 4 4 5 5 5 5 5 5 5 5 6 6 6 7 7 7 7 6 6 6 6 6 6 6 6 7 7 8 8 7 7 80.2 4 4 5 5 4 5 5 5 5 5 5 6 6 6 7 7 6 6 6 5 5 5 5 6 6 7 7 7 8 8 8 80.1 4 4 4 4 4 4 5 5 5 5 5 6 6 6 7 7 6 6 5 5 5 5 5 5 6 7 7 7 8 8 8 80.0 4 5 4 4 4 4 4 4 4 4 5 6 6 6 7 7 6 6 5 5 5 5 5 5 6 7 7 7 8 8 8
A merit-surface map, as shown above, provides a clearer picture in which the central peak reveals itself as likely to be a physically correct solution because of its narrow and compact cross-section, while others (not shown), which are merely pseudo-solutions, prove to lie on ridges and other extended features in solution space (in Mmap, this would be displayed colour-contoured.).
The new M1 and M3 commands display the three principal topographic sections centred on the currently stored cell. M1 displays all three together as thumbnails within a single screen, while M3 displays three more detailed consecutive full-screen views (of which the figure above is one example, using all-default parameters). A more general MM command generates individual maps under more detailed user control. Mmap's indexing mode can also be accessed from the IN command.
A new LC (Load Cell) command allows trial solutions to be loaded from Crysfire or Chekcell summary files to simplify such investigations. Since the next task is often to assess its topography maps, a shortcut into the M1/M3 map sequence is provided.
Another new feature is that, during indexing runs, after the summary file has been displayed, all solutions are run through a system version of Ton Spek's Le Page program then redisplayed for comparison in reduced-cell form. This highlights the relations between trial solutions, including those which are actually equivalent, though previously found in different settings (and, equally important, those that are non-equivalent derivative cells, though their volumes might have suggested that they were different settings of the same solution).
Also new is an approximate ab-initio volume estimate which is reported whenever a dataset is loaded, with a suggested rescale factor if it seems likely to be outside the volume range for which most indexing programs have been optimised. This can become important as SDPD attempts increasingly ambitious structures, even including proteins (e.g. a new form of zinc insulin: Von Dreele, 2002).
At the other end of the scale, high-pressure/high-temperature experiments often unavoidably yield sparse datasets from phases
A new EP (Extend Pattern) command can automatically extend any sparse pattern by adding higher orders of observed lines until the total has been expanded to 20. While this obviously cannot increase the amount of information present, it permits more programs to run, providing a broader basis for hypotheses about the cell (or at least sub-cell) that is present.
Finally, the logfile has been made considerably more comprehensive, so that its record now acts more nearly as an automated laboratory notebook for indexing work on each dataset name.
The author wishes to acknowledge, with thanks, all those who have contributed indexing and cell-transformation software to the Crysfire 2002 system, especially Franz Kohlbeck, Daniel Louër, Ton Spek, Daniel Taupin, Jan Visser and Per-Eric Werner, and also to draw attention to the fruitful symbiosis that exists between Crysfire and the Chekcell program by Jean Laugier &
Bernard Bochu, for graphically examining proposed solutions and investigating their probable symmetry.
Like its predecessor, Crysfire 2002 is distributed from the CCP14 website and is free for academic and other non-profit use (on academic, personal and other non-commercial computer systems).
It can now also be licensed for industrial use (see the document file Licence.txt included in the distribution, the fee being specifically for the overall system integration, the front-end, and for special software like Mmap – no charge is made for contributed code). A separate, semi-automated 32-bit Windows version (Industrial Crysfire), usable by technicians and other non-crystallographers, is in the development pipeline.
2. What is Crysfire and what does it do?
Crysfire is a system (or suite) of programs, held together by a set of interlocking scripts in the form of DOS batch files, so as to behave in most respects like a seamless whole to its users.
Its role is to provide a toolkit to assist in the preparation and enhancement of powder diffraction peak data for use in powder indexing, and especially to act as an expert system and wizard (in the Microsoft sense) to permit indexing to be carried out relatively fast and painlessly by non-specialists.
As discussed above, Crysfire will run on almost any PC from an XT to the latest GHz Pentium or Athlon, though it will obviously look its best on the latter.
Crysfire is actually the name of the launch script that bootstraps the system. It passes control to a master script, which runs the front-end program CFmain. This in turn issues the Crysfire command prompt and provides the environment that users mostly think of as Crysfire. To the user, all this happens instantaneously on a modern PC, so that the system seems like a single unified program.
When an indexing command is issued, control passes to one of the subsidiary scripts, which will run a sequence of programs that carry out the actual indexing and display its results, eventually returning to CFmain and the Crysfire command prompt.
This will be a fresh instance of CFmain with the current dataset automatically reloaded, ready for further commands.
Strictly speaking, "Crysfire" itself comprises the scripts, the CFmain front-end and a number of associated utilities, plus various modifications and post-processors for the supported indexing programs, to enable them to co-operate within this system.
Thus it does not properly include the indexing programs themselves, or at least not all of them, although they are normally included in the Crysfire distribution package for convenience.
This distinction is worth making, because the suite as a whole contains indexing software that has been contributed by a number of authors - contributions that are gratefully acknowledged. As author of the overall system, I must emphasise that I lay no claim to this contributed code and specifically assert the copyright of the various indexing-program authors in the base versions of their programs (including myself where applicable).
Thus the various indexing programs which are called via the IN (=INdex) command are either the authors' unmodified binaries (e.g. Ito, Dicvol and Treor) followed by post-processors to extract the solutions, or modified and recompiled versions (Kohl, Taup, Fjzn6, Lzon and Losh). Lastly, the new Mmap program is embedded in CFmain and called directly from the Crysfire command prompt (as MM).
Does a user need to know any of this? Usually not. Hopefully it all works seamlessly together, allowing non-specialist users to perform indexing operations on their datasets with a minimum of keystrokes and effort. By non-specialist I mean
3. Installing Crysfire
Crysfire can be downloaded from the CCP14 website in the form of a zipfile, and should be unzipped in its own directory ("folder" in Windows terminology) - the Crysfire "home directory". By default, this is taken to be C:\Crysfire, although the actual name and drive is not fixed, so long as it is specified in the small script CF_Home which sets it in the DOS environment. If C:\Crysfire is used as the home directory, no changes are required, otherwise its name will have to be edited into CF_Home.bat.
Under all Windows (and DOS) versions except XP, the installation is then completed just by running the supplied script CFsetup, which copies the two bootstrap script files (CF_Home and CFmaster) into the main Windows (or DOS) directory.
Under Windows XP, however, because changes to the Windows directory are not permitted (and automatically reversed), the automated route via CFsetup is blocked, and the Crysfire home directory path has to be added by hand to the execution PATH variable within the DOS environment (if the system has previously been running Crysfire 2000, it will already be there).
The process of adding the Crysfire directory to the PATH is usually done by editing the PATH= line in the Autoexec.bat file. If that would make the PATH line too long, one can also add a line creating a temporary PATH at the beginning of the Crysfire.bat script, or in a preliminary call of a specially-written path-setting script, for those who know how to do such things. Either way, this is not done automatically by any kind of install-wizard, but needs to be done manually using an editor – I'm not happy with programs that mess automatically with the configuration of people's systems.
Once the Crysfire bootstrap scripts are on the PATH, Crysfire can be called from whichever directory contains the data to be analysed. This is the recommended way to use it – having a separate directory or sub-directory for each problem, to keep its housekeeping in good order.
Crysfire requires about 550K of base RAM (i.e. the bottom 640K of address space) to be free for programs to use - this can be checked with the DOS Mem command. I've found that networked Windows/NT systems often have their base RAM recklessly stuffed with network drivers, etc., in which case it may become necessary to reboot temporarily without the drivers to make sufficient room available for Crysfire to run.
Crysfire makes heavy use of DOS environment variables to communicate between its subsystems, so also needs enough free space for these. Preferably make sure of this by adding a suitable "shell=" line to Config.sys. For example, under Windows 9x, this might be:
shell=C:\WINDOWS\COMMAND.COM C:\WINDOWS /e:2048 /p
Under DOS or Windows 3.x, substitute "DOS" for "WINDOWS". Under Windows ME, right-click on the Crysfire.bat icon, then go to properties | memory | initial environment and insert 2048.
4. Indexing a Powder Diffraction Dataset (in CDT format) using Crysfire 2002
The procedure described below assumes that your dataset is already available in native Crysfire format as a .CDT file.
This can be achieved by either:
a) Typing it into Crysfire as 2Theta, Q or d, using the OBsinput command (only the first two letters are significant in Crysfire commands – type Help, then C, to obtain lists of available commands in various formats).
b) Copying and pasting the appropriate list of values into the OB command via the Windows clipboard (this is often the simplest method, unless you can import the data directly as in (c) below).
c) Importing it from the peaks list file generated by XFIT or Winfit, or from a Brüker EVA or Philips UDI file (using the X2CRYS, WF2CRYS, EVA2CRYS or UDI2CRYS import programs included in the Crysfire 2002 distribution).
1) Start up Crysfire by either:
a) Opening a DOS prompt in your data directory and typing Crysfire (the recommended way). Under Windows XP, this can be done conveniently by right-clicking on the data directory within Windows Explorer, then selecting
"Open a DOS prompt".
b) Double-clicking on the Crysfire icon (if there is one).
c) Via Start | Run (i.e. the Run option in the Start menu) and typing in "Crysfire".
If you use methods (b) or (c), you may need to do some switching of directories, which can lead to complications when you launch indexing runs, so (a) is usually to be preferred.
The Crysfire banner heading should appear, followed by its command prompt: "Next command or HELP (or ?):". If instead you see "Bad command or file name", make sure that the directory containing the Crysfire system is on the DOS command PATH. If Crysfire displays a message about setting up appropriate resources, follow this advice, or seek help from someone who can.
2) At the command prompt, type LOad (or just LO, in either upper or lower case since Crysfire commands are not case- sensitive). You will be shown a listing of the available .CDT files in the current directory – use the DR command if you need to change to another drive or directory, but be aware that you can only launch indexing runs from the directory that you started from).
3) Type in the name of the dataset that you want to index (for example: Test) and press Enter. Press Enter again, if necessary, to accept any defaults, until you have returned to the Crysfire command prompt.
A very approximate ab-initio volume estimate will then be reported - suggestions about rescaling will also be offered if this is rather high. Similarly, advice about pattern-extension will be offered if you have a sparse dataset containing less than 20 observed lines.
4) a) Type in the INdex command (i.e. IN), followed at the next prompt by the 2-letter code for the indexing program (or shortcut code) that you want to launch (TP, D1, IT, FJ, TR, KL, D2, LZ, MM, DV, LS) or EX to exit back to the Crysfire command prompt, and ? for help and advice. This will start up the indexing-wizard dialogue for that program - read on for some advice about which program to choose.
b) A possible systematic order in which to apply these is broadly that shown in the list in (a) above, and as summarised in the indexing online help (obtained by typing "?"):
i) First screen for high symmetry crystal systems (cubic, tetragonal, hexagonal) with Taup (TP) and Dicvol91 in its high symmetry mode 1 (using the shortcut code D1).
ii) Then try the zone-indexing programs Ito12 (IT) and Fjzn (FJ), since these are powerful and very fast, and also relatively resistant to spurious lines.
iii) Other reasonably fast programs for any crystal system that might follow are the index-space programs Treor90 (TR) and Kohl (KL).
iv) The Dicvol91 low-symmetry mode 2 (shortcut code D2) is efficient for low-volume cells down to monoclinic, but may require several minutes and does not permit any impurity lines.
v) The combination heuristic program Lzon (LZ) specialises in the pathological dominant-zone case, and usually finds numerous low-symmetry solutions that other programs miss. Lzon is always well worth trying, though it too may take several minutes, since it will sometimes unexpectedly reveal the existence of relatively high-merit solutions after other programs have failed to come up with anything plausible. Its output also provides basis sets that can be used with Mmap and Losh - it now writes a basis-set list (BSL) file that Mmap will load automatically.
vi) Mmap's indexing mode is flexible, if relatively slow - 5 to 15 minutes for a full scan, though unlike Lzon this is not affected by excluding possible impurity lines. The overall visual appearance of the resulting merit-maps can also be used to identify datasets with pathological problems that may not be worth pursuing without further experimental work.
5) After selecting an indexing program, you will be asked how many of the observed lines to use – press Enter to accept the default (this is generally a safe response to most Crysfire prompts that don't call for information that is specific to your run, like the dataset name).
6) You will then be asked whether you want to accept all the applicable default responses, for an express route through this section. This is usually the best option for an initial run, so press Enter to accept it.
7) The express route will jump you forward to a question asking whether you want to change the 2Theta zero correction – press Enter for "no change" (if it does need adjusting, consider restarting and using Crysfire's self-calibration facilities
8) You will next be asked to confirm (or change) the filename (i.e. dataset name) to be used for this indexing run, and its one-line descriptive title. Usually it will be OK to press Enter to accept the defaults for each of these.
9) You should see a message saying that the Qdat input file has been successfully written to disk, and asking you to press Enter to continue. The indexing run is then automatically launched (unlike in Crysfire 2000, where users first had to QUit the front-end manually).
10) The indexing program itself will immediately start executing – in the case of Ito12, this should be finished in under a second on any modern PC. At the next prompt, press Enter to see Ito's short output file in an editor of your choice (default: WordPad under Win9x, etc. or Edit under DOS – these can be changed by specifying some other editor in the INDEXEDIT environment variable).
11) Scroll through the indexing output file and see whether the run appears to have been successful – (Control-End followed by one or more PageUp(s) will take you straight to a summary table near the end of the file).
12) A solution with reasonably low cell volume (for the kind of sample that you are investigating) and which indexes all or nearly all of the first 20 lines, with a good figure of merit (i.e. 20 or better, and 50+ with a modern focusing diffractometer), would be considered very promising.
The high-quality "Test" dataset converges to the same 648 A3 cell that indexes all the first 20 lines, for each of the four best solutions (obtained from different combinations of zones). The first has a figure of merit of 113.8, the remaining three all have 55.9 – the reason for this factor-of-2 difference being that the first had already taken into account a proposed C-centred Bravais-lattice, which approximately halves the number of calculated lines needed to account for the observed pattern. Although the other three also report a C-lattice, their lower figure of merit shows this to have been detected only during the final round of refinement, too late for its greater parsimony to be taken into account in the figure of merit.
13) The solution(s) may also be checked by looking for evidence of systematic absences that might suggest a reasonable spacegroup. Immediately before the summary table there will usually be a table of the observed lines and their suggested indices, for one or more of the best four solutions. Evidence of absences that suggest screw axes and/or glide planes is another indicator of probable correctness.
14) Exit by issuing the appropriate command (for WordPad that's Alt-F4; for DOS Edit, it is Alt-F, followed by X) - a brief progress message (or diagnostic) will then be displayed. Press any key (e.g. Enter, or Alt-F4) to move to the next editor display, which will be of the updated Crysfire summary file.
This contains all the solutions suggested so far for this dataset during Crysfire indexing runs, in the form of a line-per- solution display, sorted first on number of lines indexed in the first 20 (I20), then subsorted on figure of merit (as defined by each program). If no sufficiently good solutions have been found, the analysis will be halted at this point and you will be asked to press any key to restart at the main Crysfire prompt.
Let us assume that this is not the case, and that Ito has found some solutions. At this stage, having run only one program, the summary list will only contain the four solutions from Ito12. You can see more of each line by scrolling to the right (each line of text may be up to 232 characters long, though the most important columns for assessing solutions are in the leftmost screenful which is thus visible by default).
15) a) A useful parameter to check is V/V1 – the ratio of the volume of each proposed cell to that of the cell currently at the top of the list, and hence likely to be the best solution so far. This makes it easy to identify solutions that are likely to be alternative settings of the best solution because they have exactly the same volume (V/V1 = 1.00), and similarly any derivative cells with integer multiples of the volume (e.g. V/V1 = 4.00, etc.).
b) Other useful items include BL (the Bravais lattice type) and Pedigree (which provides an audit trail back into the indexing output files, to allow one to trace how that particular solution was obtained).
16) Again use the appropriate command to exit, as in step (13) above, then press any key to run the Le Page reduced cell program on each solution in the summary file and move to the next editor display.
17) This will show a revised reduced-cell summary table, which lists the Niggli reduced cell for each solution, and shows its V/V1 ratio to that of the top solution. Scroll right to see the original cell, with a V/Vreduced ratio showing what multiple of its own reduced cell that solution was.
This display can be informative about the relations between the various solutions. The reduced-cell process is a purely geometrical one - cells with identical reduced cells will generate exactly the same lattice and are actually the same cell, though possibly in different settings.
Cells with different reduced cells but some integer relation between their volumes are very probably derivative cells of each other - for example, sub- or super-cells.
Since the reduced-cell process knows nothing about systematic absences, it will show different choices of Bravais lattice for the same cell as different reduced cells, since they generate different sets of reciprocal lattice points - typically with the reduced version of the primitive cell having twice the volume of that for the centred cell (since the primitive one cannot be reduced further).
18) You will then be returned to step (4) above, with the current dataset automatically reloaded (another advance over Crysfire 2000) to launch another indexing program. The Crysfire 2002 INdex command supports 9 programs - 7 fully-automatic ones, plus Losh and Mmap (in indexing mode) which both require some user guidance.
In each case, the results will be merged and sorted into the summary file, to augment those already obtained.
Each program has its strengths and specializes in particular types of pattern, though all will succeed convincingly with a straightforward, high-quality pattern like Test (a Y2(oxalate)3.2H2O oxalate complex measured in Daniel Louër's laboratory, provided with his kind permission). If the same solution is found by several programs, this increases one's confidence that it may be correct.
19) Another criterion that can help to indicate whether or not a trial solution is a good candidate for the actual physical cell is the topography of the three central sections through the solution in the figure of merit surface.
These can be displayed as comparative thumbnails within a single screen by the new M1 command, and as three more detailed consecutive full-screen maps by the associated M3 command.
A good candidate will usually show a compact round or star-shaped peak in all three of its central sections, standing out clearly from the surrounding surface, while a solution that is merely the highest point on a ridge or other extended feature (in one or more of its sections) should be considered as suspect. These rules are not foolproof, but they provide some useful additional criteria for evaluating trial solutions.
20) The Laugier & Bochu Chekcell helper program is recommended for further evaluating the various solutions found and their settings (see section 11).
Crysfire 2002 can be downloaded free for non-profit use from the CCP14 website (www.ccp14.ac.rl), where Lachlan Cranswick has provided an online tutorial. It can also be licensed to industrial users - a pro-forma invoice is provided (as discussed earlier, this is for the use of the system as a whole and its integrated features). Chekcell is also among the many useful programs available from this site - see the last page for references.
5. Crysfire Commands
The following Crysfire commands can be issued from the main command prompt, which appears as follows (allowing for the particular version of Crysfire in use)t:
Crysfire 2002 v9.45.14 - Next command or ? for Help:
Only the first 2 characters of each command (shown in capitals) are significant.
5.1 Overview of Crysfire commands listed alphabetically by command code
AB = Set Bravais lattice absences MS = Modify SUM file (merge/unscale) CA = Calc pattern (and compare obs) OB = Input obs pattern (keyboard) CE = Input/display/edit cell data OF = Copy to outfile (on/off) CD = Directory/drive change PR = Copy to printer (on/off) DI = (Launch direct-indexing run) QC = QCalc (for specified lines) ED = Edit the observed pattern QM = QMax limit for calc pattern EF = Write End-of-File to outfile QU = QUIT (from Crysfire)
EP = Extend Pattern to 20 lines RS = Re-Scale observed d-spacings HL = Hlimits (set hkl min/max) RU = Run operating system command IM = Import a peakslist file SA = Save dataset (Crysfire or CIF) IN = Launch an indexing run SC = Self-calibration (Z2Th or T) LC = Load cell from summary file TR = Transform obs 2Theta (linear) LI = List the observed pattern VF = View a File (.SUM, .LOG, etc) LO = Load Crysfire dataset VM = View Crysfire Manual (Win9x) MM = MMap (map solution space) VE = Crysfire version/directories M1 = MMap: 1 screen of thumbnails WA = Wavelength entry/change M3 = MMap: Show 3 principal sections ZE = Zero correction in 2Theta ? or HE = HELP (general, commands, file)
QU = QUIT (from Crysfire)
5.2 Overview of Crysfire commands listed alphabetically by task/topic
Bravais lattice absences = AB Modify SUM file (merge/unscale)= MS Calc pattern (and compare Obs) = CA Obs pattern input (keyboard) = OB Cell data (input/display/edit) = CE Outfile copy (on/off) = OF Directory/drive change = CD Printer copy (on/off) = PR Edit the observed pattern = ED QCalc (for specified lines) = QC End-of-File written to outfile = EF QMax limit for calc pattern = QM Extend Pattern to 20 lines = EP QUIT (from Crysfire) = QU Hlimits (set hkl min/max) = HL Re-scale observed d-spacings = RS Import a peakslist file = IM Run operating system command = RU Index: launch an indexing run = IN Save dataset (Crysfire or CIF) = SA Index: (direct-indexing run) = DI Self-calibration (Z2Th or T) = SC List the observed pattern = LI Transform obs 2Theta (linear) = TR Load cell from summary file = LC Version/directory details = VE Load Crysfire dataset = LO View a file (.SUM, .LOG, etc) = VF MMap (map solution space) = MM View Crysfire Manual (Win9x) = VM MMap: 1 screen of thumbnails = M1 Wavelength entry/change = WA MMap: 3 principal sections = M3 Zero correction in 2Theta = ZE HELP (general, commands, file) = ?, HE
QUIT (from Crysfire) = QU
5.3 Crysfire commands grouped by task category
Apply/change general settings Input/modify observed pattern
AB = Set Bravais lattice absences OB = Input an observed pattern
HL = Set Hlimits (hkl min/max) LO = Load Crysfire dataset, incl obs QM = Set QMax limit for lines IM = Import a peakslist file
WA = Set wavelength ED = Edit the observed pattern ZE = Zero correction in 2Theta LI = List the observed pattern EP = Extend pattern to 20 lines Load/modify/save unit-cell data RS = Re-scale observed d-spacings SC = Self-calibration (Z2Th/T) CE = Input/display/edit cell data ZE = Zero correction in 2Theta LC = Load cell from SUM or CKM file TR = Transform 2Theta data (linear) LO = Load Crysfire dataset, incl cell
SA = Save dataset (Crysfire or CIF) Perform indexing operations MS = Modify SUM files (merge/unscale)
IN = Launch an indexing run
Calculate pattern, merit, lines DI = (Launch direct-indexing run) MM = MMap (explore solution space) CA = Calc pattern (compare Obs) M1 = Show 1 screen of Mmap thumbnails QC = QCalc (for specified lines) M3 = Show 3 principal Mmap sections
Job management RU = Run an operating system command
SA = Save dataset (Crysfire or CIF) QU = QUIT from Crysfire
Housekeeping, printing
CD = Change default directory/drive VF = View a file (.SUM, .LOG, etc) MF = Modify SUM files (Merge/unscale) PR = Copy output to Printer (on/off) OF = Copy output to outfile (on/off) EF = Write end-of-file to outfile RU = Run an operating system command VE = Show Crysfire version details
Help, information ?,HE = HELP (general, commands, file) VM = View Crysfire Manual (Win9x only) VF = View a file (.SUM, .LOG, etc) VE = Show Crysfire version details LI = List the observed pattern CE = Display/edit Cell Data
RU = Run an operating system command
HELP (general, commands, file) = ?, HE QUIT (from Crysfire) = QU
5.4 Crysfire commands: expanded descriptions (alphabetical by command code)
AB = ABsence = Set the Bravais lattice absences Flag
CA = CAlcpat = Calculate a pattern (and compare with observed if present) CE = CEll = Input/display cell constants (Direct, Q, Delaunay)
CD = ChgDir = Change the default directory/drive for datasets
DI = DirIndx = Launch a direct-indexing run using an edited input data file ED = EDit = Edit the observed pattern (Insert, Delete, Change, Finish) EF = EndFile = Write an End-of-File marker (ctrl-Z) to the output file EP = ExtPat = Extend a sparse Pattern to 20 lines by adding higher orders HL = HLimits = Set Hlimits for calc patterns (hmin,hmax,kmin,kmax,lmin,lmax) IM = IMport = Import dataset from peakslist file (EVA, UDI, WinFit, Xfit) IN = INdex = Launch an indexing run (ITO, DICVOL, TREOR, KOHL, LZON, etc) LC = LCell = Load a trial cell from a Crysfire or Chekcell summary file LI = LIstobs = List the observed pattern (and apply a zero correction) LO = LOad = Load a Crysfire (CRYS) Dataset, previously saved by SAve MM = MMap = Explore solution space using heuristic M-Maps (save peaks) M1 = Maps1Th = Display screen of Mmap thumbnails (3 sections, all defaults) M3 = Maps3 = Display sequence of 3 principal Mmap sections (all defaults) MS = ModSum = Modify summary files (unscale or merge summary files)
OB = OBsinp = Input an observed pattern (as 2Theta, sinsqth, Q or d) OF = OutFile = Select/deselect copying the output stream to a file PR = PRinter = Select/deselect copying the output stream to the printer QC = QCalc = Calculate Q (=10000/dsq) for specified lines
QM = QMax = Input a Qmax limit for the calc pattern (default Qobsmax+50) QU = QUit = Exit from Crysfire (and launch any waiting indexing run)
RS = RScale = ReScale observed d-spacings by changing the assumed wavelength RU = RUn = Run an operating system command, external program, etc
SA = SAve = Save the current dataset (as Crysfire .CDT format or CIF file) SC = SCal = Zero-2Theta or specimen-displacement correction by self-calibration TR = TRans = Transform 2Theta obs data by applying a linear equation
VF = ViewFile= View a file (.SUM, .LOG, etc)
VM = ViewMan = View the Crysfire Manual (Windows 9x and higher only) VE = VErsion = Show the Crysfire version and directory details
WA = WAve = Input a wavelength in Angstroms (or CU for CuKalpha1) ZE = ZEro = Input a zero correction in 2Theta (2Thcorr=2Thobs+Z2Th) ? = HELP = Help: general/input, commands, CRYS dataset file format) HELP (general, commands, file) = ?, HE
QUIT (from Crysfire) = QU
6. Technical Information
Some more detailed notes follow for the Crysfire powder-indexing system, which comprises a master script with eight pairs of subsidiary scripts, plus numerous associated programs, documentation and examples.
Crysfire runs nine of the principal powder-indexing programs automatically under MSDOS (either directly or from a Windows DOS prompt), normally taking their input data from a standard Crysfire dataset, which can be typed directly into Crysfire (OB command) or, more usually, loaded via the LO command after being imported by one of the available conversion programs such as XF2Crys. For experienced users it is also possible to run the programs directly from hand-edited datasets in a Qdat input file, or in that indexing program’s native input file format via the DI command (but only in the presence of the rest of the Crysfire 2002 system, due to its close-coupled design). [For background on powder indexing in general, see Kyotindx.wp1.]
The present distribution includes the CFmain program (which acts as an interactive front-end and indexing wizard), the various indexing programs, other associated programs, a quantity of documentation and example runs, and four programs (WF2Crys, XF2Crys, UDI2Crys and EVA2Crys) for importing data from peaks-list files written respectively by the profile-fitting programs WinFit and XFIT, from Phillips UDI files and from Bruker EVA output files. Crysfire 2002 can only use powder diffraction data in the form of line positions and does not support profile data directly.
As mentioned, the subsidiary Q2{indx} scripts require Qdat-format input files. These will typically have been written by CFmain in the course of a Crysfire run, from information provided interactively in answer to questions about the number of lines to use, etc, (for which it’s usually satisfactory to accept the defaults offered).
In the actual distribution, all its Q2{indx} script files will have a suffix of the form _xx where xx is a distribution number, as a mechanism to ensure that old versions, which do not match the current distribution, cannot be called inadvertently.
Direct-indexing runs from an indexing program's native-format input data files are also supported. These will usually have been written by Qdat, in the course of a previous run of Q2{indx} under Crysfire, and then hand-edited to adjust special features of the indexing program(s) concerned. This is equivalent to the RUN{indx} mechanism in Crysfire 2000 and earlier, which was not widely used and is not compatible with the design of Crysfire 2002, so that it had to be withdrawn and replaced by a new mechanism in Crysfire 2002 (via the DI = Direct-Indexing command) which allows native data files to be launched directly from the Crysfire command menu.
For both mechanisms, the systematic file naming conventions used throughout are those of the overall Crysfire script system to which all these scripts belong. Thus, on exit, a Crysfire run with that indexing program as its target will automatically leave suitable data files in both the above formats within the working directory.
Each of the Q2{indx} scripts described here will automatically run the target indexing program, leaving the resulting output file displayed (in brief form if available) in the editor specified in the environment variable INDEXEDIT (default: MS WordPad under Windows 9x or later, DOS EDIT under DOS and Windows 3.x - the display of such files is omitted completely if INDEXEDIT=NONE).
In order to run one of the target indexing programs successfully, the programs and scripts involved must be sufficiently recent to support the facilities needed. Thus, for example, for LZON and LOSH to be supported as Qdat targets, the Qdat version used must be at least v6.28k (i.e. Qdat628k). This should be the case for all programs in the current distribution.
In general, one should always update all the programs and scripts together from each Crysfire distribution as it becomes available. The scripts and programs from a particular distribution are aimed to be the latest versions available at that time, and are designed to work together. While this can never be completely guaranteed in the wonderful world of computing (and any warranties of suitability for a particular purpose, stated or implied, are hereby disclaimed), installing all the executables from a particular Crysfire distribution together is a good way to minimise one’s compatibility problems.
Note too that the Crysfire executables are required to be installed into a single directory - the Crysfire Home directory (by default, C:\Crysfire). Its pathname is planted in the environment by a short script CF_Home.bat, which, together with the launch script Crysfire.bat, needs to be on the DOS execution PATH.
Under all operating system versions except Windows XP, this will be done automatically if you run the supplied script CFsetup from the Crysfire home directory. Under Windows XP (because changes to the Windows directory are rejected), you will need either to modify AUTOEXEC.BAT to add the relevant directory to the PATH automatically, or run a small preliminary script to do this before each Crysfire session. See the relevant file Install.txt or XPinstal.txt for further details.
Finally, note that Crysfire depends absolutely on being able to create a number of MSDOS environmental variables through which the different parts communicate with each other. If you don’t have enough free space allocated for environmental variables, you’ll get an “Out of Environment Space” message and Crysfire will be unable to complete its run. In that case, the allocation will need to be increased, using a SHELL line in CONFIG.SYS - hopefully, Crysfire will have displayed brief notes on how to do this.
All indexing programs called within Crysfire produce log and summary files, summarising the results obtained so far for the specified dataset by that program. Cumulative log and summary files are also built up for the dataset as a whole:
{datafile}.LOG and {datafile}.SUM respectively. The logfile for each run is appended to the overall one for the dataset, and its solutions summary added to that for the dataset then sorted into descending order of I20 and Merit.
The minimum levels for inclusion vary for different indexing programs, but are typically I20 above 15 and Merit above approx.
7 to 9, where I20 is the number of “indexed” lines in the first 20 observed lines, and Merit is based on De Wolff’s M20 but calculated for “indexed” lines only (as interpreted variously by each indexing program). Note that the solutions listed are simply a verbatim record of what the indexing programs have found, and make no claims either to be correct or to have been expressed in the most appropriate crystal systems or settings. Such judgements are left to the user.
At the end of the indexing run, first the short output file, and then the sorted solutions summary, are displayed using the editor specified in environmental variable INDEXEDIT (default: WordPad or DOS EDIT, depending on the operating system).
6.1 Indexing Programs Supported by Crysfire
The following indexing programs are supported in the current Crysfire distribution (with the latest version tested shown in column 2). The version information refers to the local version used within Crysfire, and adapted and extended to run within that environment and support Crysfire facilities, such as log and summary files, etc. Only Ito, Dicvol and Treor are run from their authors' unmodified binaries (in which case the adaptations are made via a post-processor which scans their output). The adapted versions call facilities within the main Crysfire module and cannot be run as standalones. In most cases the name of the system version has been changed from that of the authors' base version, to emphasise that the original author is not responsible for any problems that might arise through these modifications.
Program Version Author(s) Documentation Q2{indx}**
Ito v12 (Ito12) (1994) Jan Visser Ito12.wp1 Q2IT
Dicvol Dicvol91 (1993) Daniel Louër Dicvol91.wp1 Q2DV
& A. Boultif
Treor Treor90 (1995) Per-Eric Werner Treor90.wp1 (.doc) Q2TR
Treor90.sht
Taup v3.3a (11Jun02) Daniel Taupin: Powder (1974) Taup9606.doc Q2TP
(extended by R. Shirley)*
Kohl v7.01b (10Jul02) Franz Kohlbeck: TMO (2001) (To follow) Q2KL
(Kohl701) (extended by R. Shirley)*
Fjzn6 v6.22a (12Jun02) Jan Visser & R. Shirley (much of Ito12.wp1 applies) Q2FJ (Fjzn622)
Lzon v6.23b (31Jul02) R. Shirley, D. Louër LzonData.doc (.txt) Q2LZ
(Lzon623) & Jan Visser
Losh v6.2b LoshFzrf (10Jul02) D. Louër & R. Shirley* LoshF62b.rtf (txt) Q2LS (LoshFz62)
Mmap v9.45.18 (2Aug02) Robin Shirley (via online help) Q2MM
(incorporated in CFmain)
ClePage v1.5 (30Apr02) Ton Spek & A.Meetsma - -
(ClePag15) Crysfire adaptation by R.Shirley
* including FZRF cell refinement & evaluation appended from Jan Visser's ITO6
** the current versions are suffixed _01 (at 2Aug02)
After some 3 years of intensive development, Crysfire is reasonably complete, but suggestions for improvement are welcomed and I hope other indexing programs (e.g. N-TREOR, AUTOX and SCANIX) may be added as opportunity permits, subject to their author's permission. To be a candidate for support by Crysfire, an indexing program must be able to run in c.550KB within an MS-DOS environment under Windows 3.x, 95, etc., (without a DOS extender), be able to use powder-line positions (rather than require full profiles), and be sufficiently mature for Crysfire to be supplied with either a good set of default parameter values or the rules to calculate them.
Real-mode under MS-DOS might be dismissed as a primitive environment, but it is computationally efficient and well suited to these compact but computationally intensive programs. A protected-mode Windows version of LZON ran 3 times slower than the otherwise-identical DOS version (in a DOS box under Windows 95). Presumably a 32-bit version would do better, but the basic argument still applies.
A 32-bit version of Crysfire for industrial use (Industrial Crysfire) is under development (using Delphi) – this will be aimed more at technicians and other non-crystallographers, with an emphasis on bulk processing and ease of use. In due course, some of these developments will feed back into general Crysfire releases, just as Industrial Crysfire will benefit from its DOS predecessors. (Plans have been dropped for a proposed more ambitious 32-bit Crysfire replacement - the "Indexer’s WorkBench" - which was to be supported under both 32-bit Windows and Linux and developed by a distributed team working via the Internet, since this did not succeed in attracting a critical mass of programming support. However, hope is not lost that a 32-bit version of Crysfire will run under Linux some day, via Kylix, Borland's Delphi equivalent)
6.2 Associated Crysfire software
Program Version Author (and date) Description
Crysfire (for Crysfire 2002) Robin Shirley (29Jun02) Crysfire bootstrap and launch script CFmaster (for Crysfire 2002) Robin Shirley (4Jul02) Master automatic-indexing script CF_Home (for Crysfire 2002) Robin Shirley (17Jun02) Short script to plant home directory path
CFsetup (for Crysfire 2002) Robin Shirley (13Jun02) Short script to set up Crysfire 2002 (not for Win/XP) CFconfrm v1.4 Robin Shirley (8Jul02) Performs initial confirmation dialogue
CFmain v9.45.18 (CFmain & Robin Shirley (2Aug02) Powder diffraction utility / indexing wizard CFma4518.ovr)
Qdat v6.28L (Qdat628L) Robin Shirley (10Jul02) Indexing-data format translator
ITlog v2.1 (ITlog21) Robin Shirley (13Jul02) Log/summary post-processor for ITO12 DVlog v2.1 (DVlog21) Robin Shirley (4Jun02) Log/summary post-processor for DICVOL91 TRlog v2.1 (TRlog21) Robin Shirley (17May02) Log/summary post-processor for TREOR90 VRatio v1.2 Robin Shirley (16Jul99) Recalculates V/V1 fields in log/summary QHead v1.2 Robin Shirley (29Jun99) Creates log/summary headings file CSort (13Aug90) Open Software Movement Filter to sort files of strings DelifNul v1.0 Robin Shirley (16May02) Deletes a specified file if empty
WhereAmI v1.0 Robin Shirley (18Jun02) Plants current directory path in the environment Unscale v1.1 (Uscale11) Robin Shirley (13Dec00) Restores scale to summary files for rescaled data MergeSum v1.1 Robin Shirley (3Jul02) Merges two Crysfire summary files
WF2Crys v1.7b Robin Shirley (24Jul02) Converts WinFit peaks file to Crysfire dataset X2Crys v1.7c Robin Shirley (2Aug02) Converts XFIT peaks file to Crysfire dataset UDI2Crys v1.30 Robin Shirley (3Jul02) Converts Philips UDI peaks file to Crysfire dataset EVA2Crys v1 Arie van der Lee (26Apr02) Converts Bruker EVA output file to Crysfire dataset Crys2CIF v 1.7b Robin Shirley (14Jun00) Converts Crysfire dataset to Powder CIF file
6.3. Disclaimers
With so much esoterica to sift through and intricate hierarchies of parameters to disentangle, it would be amazing if these pages contained no errors, even if there had been time and leisure to sort it all out (which, as anyone involved in software development will know, was far from the case). Following tradition, this manual was revised as a final task after the completion of program development and testing. Naturally I’ve tried to make it as accurate as I could manage, but this cannot be guaranteed. If you come across what seem to be errors, please let me know at R.Shirley@ surrey.ac.uk.
Note that Crysfire simply reports the possible solutions that the various indexing programs have found, which, even if physically correct, will not necessarily be in their simplest or most symmetrical settings. Different indexing programs may also have used different settings for the same solution (which will thus have related or identical V/V1 ratios). Consider using the Laugier & Bochu Chekcell program to clarify such issues and to assign probable space groups, also available from
6.4 Changing Directory within Crysfire
Crysfire uses two directory paths, both of which are fixed for the duration of a run:
1) Crysfire home directory (as defined by the CF_Home script)
2) Crysfire data directory (the directory in which the Crysfire run was launched)
In addition, the current directory for loading datasets and for reading and viewing files can be changed by issuing the DR command from a Crysfire command prompt.. Note, however, that this does not change the Crysfire data directory, and that this will be returned to automatically whenever an indexing run is launched, to ensure that the relevant summary and log files, etc., will be updated consistently and appropriately. To summarise, Crysfire always runs within the original data directory from which it was launched, but by using its DR command, datasets and cells can be loaded from elsewhere.
Note that it is risky for either the Home or Data directory path to contain long directory names. This will often work under Windows 95 or 98 (though reportedly not always under W98), it is likely to fail under Windows ME and later due to subtle changes in the way that operating system services are delivered in those environments. For the time being, the safest configuration generally is for both of these pathnames to contain only DOS-style 8.3 character names.
6.5 Etymological Note
Crysfire evolved in 1999 from its much more limited predecessor Crys2Run, and was renamed to emphasise the major changes in scope and functionality. Apart from several new indexing targets, there were many new features, such as targeted Qdat files, cumulative log and summary files for each dataset, the ability to import WinFit and XFIT peaks files, and much more. Crysfire 2000 was an enhanced release in 2000, and Crysfire 2002 is of course the present release, largely rewritten and greatly enhanced and extended.
The name “Crysfire” reflects the multi-target approach promoted by Lachlan Cranswick in his CCP14 website tutorials (who, as you can see, succeeded in wearing down my resistance to what I tended to see as a possible de-skilling of powder indexing).
“Crysfire” brings echoes too of “crossfire” (between the different programs), “quickfire” (how, hopefully, it will operate), and perhaps a reference to what I felt I’d stepped into from the frying pan, while trying to get it finished in time for its original release at the Glasgow IUCr Congress in August 1999.
7. Crysfire (.CDT) Dataset File Format
Ordinary Crysfire users should never need to concern themselves with the details of the .CDT dataset file format described in this section, since all relevant operations are performed automatically by the Crysfire system. This information is provided for programmers who may wish to support this format in their own software (as for example has been done in the Laugier & Bochu Chekcell program).
7.1 General Properties
A Crysfire dataset file (.CDT) is composed entirely of ASCII text. Items within any line are comma delimited, with strings in double quotes (so string items must not themselves contain any double-quote ["] characters). All lengths are in
Angstroms; all reciprocal lengths are in reciprocal Angstroms; all powder constants and related quantities are in Q-units of 10000/dsq (where dsq is in Angstroms-squared); all angles are in degrees;
The present format dates from v9.30 (May 1999), when the first 3 (starred) lines were added at the beginning of the dataset (as described in the "Warning line"). This is now principally of historical interest, since it's doubtful whether there are any users out there caught in a timewarp and still running a pre-1999 version.
7.2 Detailed Description
*Datestamp line (approx 60 chars: one line, version and date/timestamp)
(Note: to flag the presence of the current format, this line must start with CRYS or Crys and exceed 8 chars)
*Dataset title (up to 72 chars of description: one line, always present)
*Warning line (69 chars - To read with CRYS before v9.30, delete first 3 lines) Dataset header (stored as 1 line, always present):
Dset = dataset name, Nobs = Number of obs lines,
Ctype = Cell input type (0/1/2/3 = none/direct/Q/Delaunay), Ncalc = Number of calc lines,
Qmax (for calc lines), Gflag (1 if Hlimits stored), W0 = wavelength (in A),
Z2Th (zero correction to be added to 2Theta values), Dflag (0/1 = obs data given as Q/2Th),
Abs = Absences flag (Bravais)
(Iflag is not stored explicitly but inferred from whether OI(1) is non-zero in the obs pattern) Observed pattern (stored 1 line per obs line, only present if Nobs non-zero):
For i = 1 to Nobs
OQ = Qobs,
OH,OK,OL = hkl assigned to this line (if any, otherwise zeroes), OT = 2Theta (degrees),
OI = Intensity code / Intensity (either a qualitative code from 0 to 9, or a measured intensity) Cell data (stored as 6-row table, only present if Ctype non-zero):
for i = 1 to 6
DD = direct cell (A, deg), PP = Delaunay constants, QQ = powder constants, RR = reciprocal cell (A-1,deg),
DSC = direct sin & cos, RSC = reciprocal sin & cos,
GL = Given Hlimits (hmin,hmax,kmin,kmax,lmin,lmax)
Calc pattern (stored 1 line per calc line, only present if Ncalc non-zero. These are provided only for reference since they are recalculated whenever they are needed within CFmain, hence it is always harmless to set Ncalc = 0 and omit them):
for i = 1 to Ncalc CQ = Qcalc, CH,CK,CL = hkl
8.1 Copyright and Licensing
The Crysfire system is freely available for non-profit use, but it is not public domain. Copyright in all its parts is asserted by and reserved by the relevant authors.
Thus the overall Crysfire system and user interfaces, including its scripts and its associated programs (CFmain, CFconfrm, DelifNul, WhereAmI, Qdat, ITlog, DVlog, TRlog, VRatio, QHead, WF2Crys, XF2Crys, UDI2Crys, Crys2CIF) as listed above (but excluding indexing programs contributed by other authors) are © R.Shirley, 2002.
Similarly, copyright (or copyleft) is reserved by the various authors of the indexing programs (including myself, where applicable). Derivative copyright in the adaptations and extensions to the indexing programs made to support the user interfaces within Crysfire is © R.Shirley, 2002, subject to the rights of the authors of the relevant base versions of those programs. Licensing fees for commercial use of Crysfire cover only my user interfaces and modifications to those indexing programs, and expressly make no charge for any contributed code, which is distributed freely in the same spirit that it was received.
For commercial licences covering use of all user interfaces and adaptations in the Crysfire system for which I hold the copyright (contributed code remains free of charge), and for confidential consultancy, please contact me at [email protected]. Further information is given in the associated document file Licence.txt.
8.2 Distribution and Tutorial
The Crysfire suite is distributed free for non-profit use via the CCP14 web site (http://www.ccp14.ac.uk), where detailed tutorials have been provided by Lachlan Cranswick. It is also included in the CCP14 Xtal Nexus CD-ROM.
For commercial distribution, please contact me at [email protected].
8.3 Conditions of Use
For non-profit use, the following conditions apply:
1) This software may only be distributed on the same terms that it was received, which is freely for non-profit use.
Neither the original versions nor any derived or modified versions may be sold or incorporated in any commercially distributed system, without the express permission in writing of the relevant copyright holders. These terms shall be binding on all subsequent recipients.
2) Users who are employees of a commercial company may only use Crysfire under this free licence if (a) their use is exclusively for academic or other non-profit purposes; (b) their employer makes no use of any of their results for any purpose, including publicity; (c) Crysfire is installed and used for this purpose only on non-company computer(s).
3) If use of the Crysfire suite makes possible a published paper, then both the Crysfire suite itself and any indexing programs that contributed materially to this result should be cited in the references section of the paper (some examples of possible references to cite are given below).
8.4 General Limitations
Crysfire assists users to find possible solutions to the powder-indexing problem, in the form of complete or partial unit cells.
Because this is a complex problem in heuristics and induction which does not permit solutions to be identified with certainty (until they are confirmed by structure determination), any trial cells that are reported can only be suggestions, and the final responsibility for any decisions must lie with the user.
Although every effort has been made to ensure that the software in the Crysfire system operates correctly and in accordance with its documentation, Crysfire is distributed strictly "as is". Responsibility for interpreting its output lies exclusively with the user and no liability direct or indirect shall be incurred by any author or distributor for any losses that may result from its output or any interpretation of its output. It is the position of myself and all other contributing authors that, since the output can only contain suggestions for informed evaluation by the user, no reasonable use of the system can give rise to any liability.
It is a condition for using Crysfire that, as user, you understand and accept this situation.
9. References
9.1 Crysfire Suite
R. Shirley (2002), The Crysfire 2002 System for Automatic Powder Indexing: User’s Manual, The Lattice Press, 41 Guildford Park Avenue, Guildford, Surrey GU2 7NL, England. (i.e. this manual)
9.2 Specific Indexing Programs
ITO:
Visser, J. W. (1969), A Fully Automatic Program for Finding the Unit Cell from Powder Data, J. Appl. Cryst., 2, 89-95.
DICVOL:
Boultif, A. & Louër, D. (1991), Indexing of powder diffraction patterns for low-symmetry lattices by the successive dichotomy method, J. Appl. Cryst., 24, 987-993.
Louër, D. & Vargas, R. (1982), Indexation Automatique des Diagrammes de Poudre par Dichotomies Successives, J. Appl.
Cryst., 15, 542-545.
TREOR:
Werner, P.-E., Eriksson, L. & Westdahl, M. (1985), TREOR, a Semi-Exhaustive Trial-and-Error Powder Indexing Program for All Symmetries, J. Appl. Cryst., 18, 367-370.
TAUP:
Taupin, D. (1973), A Powder-Diagram Automatic-Indexing Routine, J. Appl. Cryst., 6, 380-385.
(A later paper exists, but it does not refer to the base version used in the Crysfire system.) KOHL:
Kohlbeck, F. & Hörl, E. M. (1976), Indexing Program for Powder Patterns Especially Suitable for Triclinic, Monoclinic and Orthorhombic Lattices, J. Appl. Cryst., 9, 28-33.
Kohlbeck, F. & Hörl, E. M. (1978), Trial and error indexing program for powder patterns of monoclinic substances, J. Appl.
Cryst., 11, 60-61.
FJZN6:
Shirley, R. (2002), A modified version of Visser’s ITO zone-indexing program, using the Ishida & Watanabe PM criterion for zone evaluation, (not yet published). See also Visser (1969) for the ITO6 base version, and Ishida & Watanabe (1982) for the PM criterion.
LZON, LOSH:
Shirley, R. & Louër, D. (1978), New powder indexing programs for any symmetry which combine grid-search with successive dichotomy, Acta Cryst., A34, S382.
PM Criterion (used in FJZN6 and LZON):
Ishida, T & Watanabe, Y. (1982), A criterion method for indexing unknown powder diffraction patterns, Z. Krist., 160, 19-32.
9.3 General Powder Indexing
(a brief selection, concentrating on material relevant to Crysfire users)Calvert, L. D., Flippen-Anderson, J. L., Hubbard, C. R., Johnson, Q. C., Lenhert, P. G., Nichols, M. C., Parrish, W., Smith, D.
K., Smith, G. S., Snyder, R. L. & Young, R. A. (1980), Standards for the publication of powder patterns: the American
Ito, T. (1950), X-ray Studies on Polymorphism, Maruzen, Tokyo, 187-228.
Louër, D. (1998), Advances in powder diffraction analysis, Acta Cryst. A, 54, 922-933.
Mighell, A. D. & Santoro, A. (1975), Geometrical Ambiguities in the Indexing of Powder Patterns, J. Appl. Cryst., 8, 372-374.
Mighell, A. D. (1976), The Reduced Cell: Its Use in the Identification of Crystalline Materials, J. Appl. Cryst., 9, 491-498.
Mighell, A. D. & Stalick, J. K. (1980), The reliability of powder indexing procedures, in Accuracy in Powder Diffraction, ed.
Block, S. & Hubbard, C. R., NBS Spec. Publ. 567, 393-403.
Shirley, R. (1975), Recent advances in determining unknown unit cells from powder diffraction data, Acta Cryst., A31, S197.
Shirley, R. (1978), Indexing powder diagrams, in Crystallographic Computing, ed. Schenk, H., Olthof-Hazekamp, R., van Koningsveld, H. & Bassi, G. C., Delft University Press, Holland, 221-234.
Shirley, R. (1980), Data accuracy for powder indexing, in Accuracy in Powder Diffraction, ed. Block, S. & Hubbard, C. R., NBS Spec. Publ. 567, 361-382.
Shirley, R. (1984), Measurement and Analysis of Powder Data from Single Solid Phases, in Methods and applications in crystallographic computing, Hall, S. R. & Ashida, T., Clarendon Press, Oxford, 411-437.
Shirley, R. (2000), Progress in Automatic Powder Indexing, Proceedings of EPDIC-7, Barcelona, May 2000 (to be published).
Smith, G. S. & Snyder, R. L. (1979), FN: A Criterion for Rating Powder Diffraction Patterns and Evaluating the Reliability of Powder-Pattern Indexing, J. Appl. Cryst., 12, 60-65.
Snyder, R. L., Johnson, A. C., Kahara, E., Smith, G. S. & Nichols, M. C. (1978), An analysis of the powder diffraction file, Lawrence Livermore Laboratory, University of California, Report UCRL-52505.
Werner, P.-E. (1976), On the Determination of Unit-Cell Dimensions from Inaccurate Powder Diffraction Data, J. Appl.
Cryst., 9, 216-219.
Wolff, P. M. de (1963), Indexing of Powder Diffraction Patterns, Adv. X-Ray Anal., 6, 1-17.
Wolff, P. M. de (1968), A Simplified Criterion for the Reliability of a Powder Pattern Indexing, J. Appl. Cryst., 1, 108-113.
Wolff, P. M. de (1972), The definition of the indexing figure of merit M20, J. Appl. Cryst., 5, 243.
10. Technical Reference Notes on Individual Indexing Programs
The following sub-sections contain detailed technical notes on the general properties and implementation characteristics of each of the indexing programs supported by the Crysfire INdex command.
The sequence begins with the classic trio of Ito, Dicvol and Treor, then follows the order given in the INdex command menu:
IT, DV, TR
TP, FJ, KL, LZ, MM, LS Sub-sections:
10.1 IT = Ito (VIsser) 10.2 DV = Dicvol (Louër) 10.3 TR = Treor (Werner) 10.4 TP = Taup (Taupin: Powder) 10.5 FJ = Fjzn (Visser & Shirley) 10.6 KL = Kohl (Kohlbeck: TMO) 10.7 LZ = Lzon (Shirley, Louër & Visser) 10.8 MM = Mmap (Shirley)
10.9 LS = Losh (Louër & Shirley)
10.1 ITO (Jan Visser)
Deductive search in index space by zone-indexing
ITO12 performs best when given 30-40 accurately measured powder lines. It is relatively little affected by impurity lines unless they are among the first 5 lines (hardly at all if outside the first 20). It is optimised for the lower symmetry systems from orthorhombic downwards – consequently high-symmetry lattices may well get reported in an orthorhombic setting, perhaps with a note that a higher symmetry setting may exist. The Bravais lattice is inferred, and Bravais lattice absences taken into account when calculating M20. During refinements, an attempt will be made to estimate and refine the 2Theta zero correction.
(See also FJZN6 for a variant that will sometimes succeed where ITO12 fails.)
Note that ITO12 is functionally the latest version of the ITO program - although a later version ITO15 exists, it differs from ITO12 only by providing an interactive data-file interface on PCs, which is irrelevant when ITO is run under Crysfire.
Q2IT Runs the ITO12 zone-indexing program automatically on the dataset given in targeted Qdat input file %1.QIT (written, for example, by Crysfire), using Qdat/ITO12 defaults unless specified otherwise (or a direct indexing run [with the Crysfire DI command] that by-passes Qdat if %2 = -Run).
Typical run times: a few seconds on a 200MHz Pentium.
usage Q2IT {datafile} {run_flag}
where {datafile} is the base name of the %1.QIT targeted Qdat input file (i.e. without its .QIT extension)
{run_flag} is the optional flag "-Run" which, if present, indicates that
this is to be a direct run, by-passing QDAT (in which case the {datafile} extension will be .ITD) The same {datafile} name is used automatically when naming all subsequent files in the run:
Qdat targeted input file = {datafile}.QIT Qdat output listing file = {datafile}.QDO ITO12 input data file = {datafile}.ITD ITO12 main output file = {datafile}.ITO ITO12 short output file = {datafile}.ITS ITO12 input verification = {datafile}.ITV ITO12 solutions-log = {datafile}.ITG ITO12 solutions-summary = {datafile}.ITM
The solutions log and summary are also appended to the log and summary files for the specified dataset: {datafile}.LOG and {datafile}.SUM respectively. {datafile}.SUM is then sorted into descending order of I20 and Merit (the ITlog post- processor does not use any acceptance criteria of its own based on I20 or M20, but simply reports the “4 most probable solutions” that are listed in the ITO12 output files).
As usual, at the end of the indexing run, first the short output file, and then the sorted solutions summary, are displayed using the editor specified in environmental variable INDEXEDIT (default: WordPad under Win9x, etc. or Edit under DOS). Thus the following files provide a record of all runs for the specified dataset, after updating with the current run as described above:
Dataset solutions-log = {datafile}.LOG
Dataset solutions-summary = {datafile}.SUM (sorted)
Dataset solutions-summary = {datafile}.SMH (sorted and with headings) Le Page reduced-cell analysis = {datafile}.CLO (in sorted order)
Le Page reduced-cell summary = {datafile}.CLM (headed summary) Old dataset solutions-log = {datafile}.LGK (backup)
Old dataset solutions-summary = {datafile}.SUM (backup) Old Le Page analysis = {datafile}.COK (backup) Old Le Page summary = {datafile}.CMK (backup)
