DOCTORAL THESIS

Title

Application of service composition mechanisms

to Future Networks architectures and Smart

Grids

Presented by

Ramon Martín de Pozuelo Genís

Centre

Escola Tècnica Superior d’Enginyeria Electrònica i

Informàtica La Salle

Department

Departament d’Informàtica

Directed by

Dr. Agustín Zaballos Diego y Dr. Francesc Pinyol

Margalef
