Stereo Video Surveillance Multi-agent System: New Solutions for Human Motion Analysis
Pere Marti-Puig · Sara Rodríguez · Juan F. De Paz · Ramon Reig-Bolaño · Manuel P. Rubio · Javier Bajo
© Springer Science+Business Media, LLC
Abstract This article presents a distributed agent-based system that can process the visual information obtained by stereoscopic cameras. The system is embedded within a global project whose objective is to develop an intelligent environment for location and identification within depen- dent environments that merges with other types of technolo- gies. In this kind of environments, vision algorithms are very costly and require a lot of time to produce a response, which is highly inconvenient since many applications can require action to be taken in real time. A multi-agent system (MAS) can automate the process of analyzing images obtained by cameras, and optimize the procedure. This study presents
P. Marti-Puig · R. Reig-Bolaño
Department of Digital and Information Technologies, University of Vic, C. de la Laura 13, 08500 Vic (Barcelona), Spain P. Marti-Puig
e-mail:[email protected] R. Reig-Bolaño
e-mail:[email protected] S. Rodríguez (
) · J.F. De PazDepartment of Informatics, University of Salamanca, Plaza de la Merced s/n, 37008 Salamanca, Spain
e-mail:[email protected] J.F. De Paz
e-mail:[email protected] M.P. Rubio
Engineering Graphics Department, University of Salamanca, Avd.
Requejo no 33, 49001 Zamora, Spain e-mail:[email protected]
J. Bajo
Department of Informatics, Pontifical University of Salamanca, Compañía, 5, 37002 Salamanca, Spain
e-mail:[email protected]
a MAS that can process stereoscopic images to detect and classify people by combining a series of novel techniques.
The article shows in detail the combination of techniques used to perform the detection process. The process can be subdivided into human detection, human tracking, and hu- man behavior understanding. With the addition of a case- based reasoning (CBR) model, the system can also incor- porate reasoning capabilities. The system was tested under different conditions and environments.
Keywords Multi-agent systems · Stereo processing · Human detection · Case based reasoning
1 Introduction
One of the greatest challenges for the scientific community is to find more effective means of providing care for the growing number of people that make up the disabled and elderly sector [18]. The importance of developing new and more cost-effective methods for administering medical care and assistance to this sector of the population is underscored when we consider current tendencies. Artificial intelligent systems have been recently examined as potential medical care supervisory systems. Among those systems are, multi- agent systems (MAS) [1,10,23,26] for elderly and depen- dent persons, providing continual support in the daily lives of these individuals; other examined systems are artificial vision systems, where we find medical image analysis and high level computer vision [47,64]. The study of artificial vision, specifically stereoscopic vision, has been the object of considerable attention within the scientific community over the last few years. Image processing applications are varied and include aspects such as remote measurements, biomedical images analysis, character recognition, virtual
