USER GUIDE USUARIO GUÍA DEL USER GUIDE 5U000531C0A REV.00

Texto completo

(1)USER GUIDE. USER GUIDE. 5U000531C0A REV.00. GUÍA DEL USUARIO.

(2) User Guide.

(3) CHAPTER 1. BEFORE USING BEFORE USING ...............................................................................................7 INSIDE THE PACKAGE................................................................................................8 HANDSET DESCRIPTIONS .........................................................................................9 KEY DESCRIPTIONS................................................................................................ 11 DISPLAY INDICATORS ............................................................................................ 12 INSTALLING THE BATTERY..................................................................................... 17 REMOVING THE BATTERY ...................................................................................... 18 CHARGING THE BATTERY....................................................................................... 18 USING A microSDTM CARD ..................................................................................... 20 BATTERY HANDLING INFORMATION..................................................................... 21. CHAPTER 2. BASIC OPERATION BASIC OPERATION ........................................................................................23 TURNING THE PHONE ON AND OFF....................................................................... 24 USING THE TOUCHSCREEN .................................................................................... 24 USING THE HOME SCREEN .................................................................................... 26 LOCKING OR UNLOCKING THE TOUCHSCREEN AND KEYS ..................................... 28 USING THE TASK MANAGER .................................................................................. 29 MENU SUMMARY ................................................................................................. 30 MAKING A CALL..................................................................................................... 34 ANSWERING A CALL.............................................................................................. 34 MISSED CALL NOTIFICATION ................................................................................. 34 WAIT/PAUSE FEATURE .......................................................................................... 35 MAKING AN INTERNATIONAL CALL ...................................................................... 36 2. 3-WAY CALLING .................................................................................................... 36 CALL WAITING FUNCTION ..................................................................................... 36 CALLING A NUMBER FROM CONTACTS................................................................. 37 ADJUSTING THE MASTER VOLUME ....................................................................... 37 SPEAKERPHONE MODE ......................................................................................... 37 AVAILABLE OPTIONS DURING A CALL................................................................... 38 MAKING AN EMERGENCY CALL ............................................................................ 38 USING THE DIRECTORY SERVICE............................................................................ 39. CHAPTER 3. MEMORY FUNCTION MEMORY FUNCTION.....................................................................................41 ENTERING TEXT ..................................................................................................... 42 STORING A PHONE NUMBER................................................................................. 44 EDITING CONTACT ENTRIES ................................................................................... 46 BACKUP ASSISTANTTM .......................................................................................... 48 SENDING A NAME CARD ....................................................................................... 48 SPEED DIALING...................................................................................................... 49. CHAPTER 4. MENU FUNCTION MENU FUNCTION..........................................................................................47 RECENT CALLS ....................................................................................................... 48 MY VERIZON .......................................................................................................... 50 VOICE COMMANDS................................................................................................ 50 CALCULATOR.......................................................................................................... 53 TIP CALCULATOR.................................................................................................... 54 3.

(4) CALENDAR............................................................................................................. 54 ALARM CLOCK ....................................................................................................... 56 STOP WATCH .......................................................................................................... 57 WORLD CLOCK....................................................................................................... 57 UNIT CONVERTER .................................................................................................. 58 NOTEPAD ............................................................................................................... 58 USB MASS STORAGE ............................................................................................. 59 AIRPLANE MODE ................................................................................................... 59 BLUETOOTH ........................................................................................................... 60 SOUND SETTINGS .................................................................................................. 63 DISPLAY SETTINGS ................................................................................................ 66 TOUCH SETTINGS................................................................................................... 69 PHONE SETTINGS .................................................................................................. 70 CALL SETTINGS...................................................................................................... 76 MEMORY ............................................................................................................... 78 USB MODE ............................................................................................................. 80 PHONE INFO .......................................................................................................... 81. CHAPTER 5. CAMERA CAMERA .......................................................................................................83 TAKING A PHOTO ................................................................................................... 84 VIEWING PHOTOS.................................................................................................. 85 USING PHOTO OPTIONS......................................................................................... 85 RECORDING A VIDEO ............................................................................................. 86 VIEWING VIDEOS................................................................................................... 87 4. USING VIDEO OPTIONS.......................................................................................... 87 USING CAMERA & CAMCORDER SETTINGS........................................................... 88. CHAPTER 6. MEDIA CENTER MEDIA CENTER .............................................................................................91 MUSIC & TONES ..................................................................................................... 92 PICTURE & VIDEO .................................................................................................. 96 GAMES................................................................................................................... 98 Mobile WEB........................................................................................................... 99 BROWSE & DOWNLOAD........................................................................................ 99 EXTRAS ................................................................................................................ 100. CHAPTER 7. MESSAGING MENU MESSAGING MENU .....................................................................................101 NEW MESSAGE NOTIFICATION ............................................................................ 102 CREATING A NEW MESSAGE ............................................................................... 102 VIEWING RECEIVED AND SENT MESSAGES......................................................... 105 DELETING RECEIVED AND SENT MESSAGES ....................................................... 106 VIEWING DRAFT MESSAGES ............................................................................... 106 DELETING DRAFT MESSAGES .............................................................................. 106 MANAGING THE TEMPLATE BOX ......................................................................... 106 CHANGING THE MESSAGE SETTINGS .................................................................. 107 ACCESSING YOUR VOICEMAILS............................................................................ 108 EMAIL & IM ......................................................................................................... 109. 5.

(5) 1. CHAPTER 8. SAFETY AND WARRANTY SAFETY AND WARRANTY ...........................................................................111 SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES............................. 112 SAFETY INFORMATION FOR FCC RF EXPOSURE .................................................. 117 SAR INFORMATION.............................................................................................. 118 HEARING AID COMPATIBILITY (HAC) FOR WIRELESS TELECOMMUNICATIONS DEVICES ............................................................................................................... 120 FDA CONSUMER UPDATE .................................................................................... 122 AVOID POTENTIAL HEARING LOSS ...................................................................... 130 FCC COMPLIANCE INFORMATION........................................................................ 132 12 MONTH LIMITED WARRANTY ........................................................................ 133. 6. BEFORE USING. This chapter provides important information about using the HOTSHOTTM including: INSIDE THE PACKAGE. REMOVING THE BATTERY. HANDSET DESCRIPTIONS. CHARGING THE BATTERY. KEY DESCRIPTIONS. USING A microSDTM CARD. DISPLAY INDICATORS. BATTERY HANDLING INFORMATION. INSTALLING THE BATTERY.

(6) INSIDE THE PACKAGE. HANDSET DESCRIPTIONS. This package should include all items pictured below. If any are missing or different, immediately contact the retailer where you purchased the phone.. Standard Battery. 01. 1 2. Pre-installed 2 GB microSDTM Card. Product Safety & Warranty Brochure. 8. Wall/USB Charger. 03 04 05 07 08. 4. 1. Lock/Power Key 2. Earpiece 3. Touchscreen 4. Home Key Battery Cover. 6. 06. PRODUCT SAFETY AND WARRANTY INFORMATION. Quick Start Guide. 02. 7 3. Handset. 5. 5. Wrist Strap Eyelet 6. Headset Jack 7. Volume Keys. USB Cable. 9.

(7) HANDSET DESCRIPTIONS. KEY DESCRIPTIONS The following list correlates to the previous page’s phone illustration.. 8 9. 11. 12 10 13 14. 8. Self-Portrait Mirror 9. Speaker 10. microSDTM Card Slot 11. Camera Lens. 10. 12. Charging/Data Port 13. Voice Commands Key 14. Camera/Video Key. 1. Lock/Power Key: With the phone unlocked, press to lock the phone. Press and hold to turn the phone on or off. 2. Earpiece: Allows you to hear the other caller. 3. Touchscreen: Tap the touchscreen to access the menu or perform phone functions. 4. Home Key: Press to return to the Menu mode screen. In Menu mode, press to view the touchscreen in 3-way view. Press and hold to open the Task Manager screen. 5. Wrist Strap Eyelet: Accessory eyelet (attach optional straps and lanyards – purchased separately). 6. Headset Jack: Plug in an optional 3.5mm headset for convenient handsfree conversations or for listening to music. 7. Volume Keys: With the phone unlocked, from Menu mode, press to adjust the phone’s volume. When a call comes in, press to silence the call ringtone. During a call, press to adjust the earpiece volume. In Speakerphone mode, press to adjust the speaker volume. During playback, press to adjust the music volume. 8. Self-Portrait Mirror: Displays your reflection when taking photos or recording videos. 9. Speaker: Music, ringtones, and sounds are played through the external speaker. 10. microSDTM Card Slot: A 2GB microSDTM card comes pre-installed to increase memory capacity. 11. Camera Lens: The lens of your built-in camera and camcorder.. 01 02 03 04 05 06 07 08. 11.

(8) 12. Charging/Data Port: Connects to the USB cable for data transferring or charging when attached to the Wall/USB Charger. 13. Voice Commands Key: With the phone unlocked, from Menu mode, press to launch the Voice Commands menu. 14. Camera/Video Key: With the phone unlocked, from the Menu mode screen, press to turn on the camera; Press and hold to turn on the camcorder. In Camera mode, press to take a photo, or in Camcorder mode, press to record a video.. DISPLAY INDICATORS Icon. Icon Descriptions D Signal Strength: Indicates your phone is in the digital network. More bars indicate a stronger signal. 3G Signal Strength: Indicates your phone is in the EVDO (3G) network. More bars indicate a stronger signal. 1X Signal Strength: Indicates your phone is in the CDMA 1X network. More bars indicate a stronger signal. 3G & 1X Signal Strength: Indicates your phone is in the EVDO (3G) and CDMA 1X networks. More bars indicate a stronger signal. 3G & D Signal Strength: Indicates your phone is in the EVDO (3G) and digital networks. More bars indicate a stronger signal. Airplane Mode: Transmitting and receiving information is restricted. Music Only Mode: Indicates your phone is in Music Only mode. Roaming: Indicates your phone is outside of the home service area.. 12. Icon. Icon Descriptions Femto Cell: Indicates that this area has enhanced service coverage indoors. SSL (Secured Socket Layer): Indicates that secure communication between client and server has been established during data communication using encryption.. 01 02 03. Voice Privacy: Indicates Voice Privacy mode is active.. 04. Data Call: Indicates a data call is in progress.. 05. Dormant: Indicates phone is in a dormant state during a data call. Phone reverts to Dormant mode when there hasn't been activity on a page for some time - the connection is still active and you can make and receive calls.. 06. No Service: Indicates no phone service is available.. 08. 07. TTY: Indicates TTY mode is active. Voice Call: Indicates a voice call is in progress. E911: Location (GPS) service is set to E911 Only for emergency calls. Location On: Location (GPS) service is set to Full Detection. Phone Lock: Indicates Phone is locked. Bluetooth: Indicates Bluetooth® mode. Bluetooth Active: Indicates Bluetooth Active mode. Bluetooth Connected: Indicates a Bluetooth device is paired with your phone.. 13.

(9) Icon. Icon Descriptions Music Pause Mode: Indicates that music playback is paused. Music Playing Mode: Indicates that music is playing.. Icon. Icon Descriptions Alarm On: Indicates an alarm is set. Speakerphone: Indicates Speakerphone mode is active.. AVR Active: Advanced Voice Command feature is active.. Battery Level: Indicates the battery charging level - the more bars, the stronger the power. All Sounds Off: Indicates phone sounds are set to off.. Dialed Call. Missed Call. 06. New Contact Icons. Vibrate On: Indicates Alert Vibrate for incoming calls is set to on.. Mobile. WL Messenger. Voicemail: Indicates you have a new voicemail.. Mobile 2. Ringtone. Home. Message Tone. Business. Favorite. Fax. Group. Personal E-mail. Speed Dial. Business E-mail. Title. Email: Indicates you have new email.. IM Screen Name. Company. CMAS Alert: Indicates a new CMAS message.. AIM. Birthday. Alert Email: Indicates a new email.. Yahoo!. Note. Alert Voicemail: Indicates a new voicemail. Missed Calls: Indicates you have missed calls. Message: Indicates you have new messages. Alert Message: Indicates a new message.. 04 05. Received Call. Alarm Only: Indicates the phone will alert you only with an alarm tone.. 02 03. Recent Call Icons. AVR Listening: Indicates your phone recognizes your voice command.. 01. 07 08. Calendar Appointment: Indicates an alarm for your appointment is active. 14. 15.

(10) INSTALLING THE BATTERY. Message Icons. 16. 1. Slide the battery into the slot (1) by aligning the contacts and push down (2) until you hear the “click.”. Unread Message. Received Unread Message. Read Message. Received Read Message. 01. Unread EMS. Multiple Message Sent. 02. Read EMS. Message Delivered. Unread MMS Notification. Multiple Message Delivered. Read MMS Notification. Sent Message Delivery Failed. Unread Corrupt Message. Multiple Message Failed. Read Corrupt Message. Pending Message Send. Unread Wap Push. Multiple Message Pending. Read Wap Push. Incomplete Delivery. Unread MMS. Multiple Message Incomplete. Read MMS. Text Message Draft. Unread CMAS. Picture Message Draft. Read CMAS. Priority. Sent Message. Message Locked. 03 04 Correct. 05. Incorrect. 06 2. Align the cover tabs with the slots on the back of the phone and slide the battery cover onto the unit until it snaps into place.. 07 08. If the battery is not correctly placed in the compartment, the phone will not turn on and/or the battery may detach during use.. Correct. Incorrect. 17.

(11) REMOVING THE BATTERY 1. To remove the battery cover, insert your finger tip into the slot (1), then push down on the top of the battery cover and slide it off (2). 2. Insert your fingernail into the slot and lift the battery from the compartment.. If the battery connector is not properly aligned, damage could occur to the charging connector and the phone may not be charged.. 01 Correct. CHARGING THE BATTERY 1. Connect the USB data cable into the cableless wall adapter. 2. Plug the USB data cable into the phone’s Charging/ Data Port (making sure to align the connector as it appears in the image to the right) and the wall adapter end into an electrical outlet.. 18. 02 03 04. Correct 3. Align the cover tabs with the slots on the back of the phone and slide the battery cover onto the unit until it snaps into place.. Incorrect. Incorrect. 3. To remove the wall charger, unplug the USB data cable from the phone’s Charging/Data Port. t When you charge the battery with the handset powered off, you will see a charging status screen. After charging is completed, the Charge Complete message appears and you cannot operate the phone until it is powered on. To turn your phone on, press and until your display turns on. hold the Power Key t The battery may not be fully charged at the time of purchase. Fully charge the battery before using. t It is more efficient to charge the battery with the handset powered off. t Battery operating time gradually decreases over time. t If the battery fails to perform normally, you may need to replace the battery.. 05 06 07 08. 19.

(12) USING A microSDTM CARD. A microSDTM card stores sounds, videos, images, photos, music, and other files. A 2GB microSDTM card comes pre-installed in your phone.. INSTALLING A microSDTM CARD To install your microSDTM card:. 1. Remove the battery cover and the battery. 2. Press the microSD TM card into the slot with the gold contacts facing down. 3. Replace the battery and the battery cover. To prevent possible damages, please keep the microSDTM card slot closed at all times regardless of whether a microSDTM card is inserted or not.. REMOVING A microSDTM CARD To remove the microSDTM card:. 1. Remove the battery cover and the battery. 2. Gently pull the exposed edge of the microSDTM card with your fingertip to release it from the slot. 3. Remove the microSDTM card. 4. Replace the battery and the battery cover. To ensure the proper function of removable memory, please use a microSDTM card.. 20. BATTERY HANDLING INFORMATION DO’S. t Only use the battery and charger approved for use with the HotshotTM. t0OMZVTFUIFCBUUFSZGPSUIFTZTUFNGPSXIJDIJUJTTQFDJGJFE t0OMZVTFPSSFQMBDFUIFCBUUFSZXJUIBDIBSHJOHTZTUFNPSBOPUIFSCBUUFSZUIBUIBTCFFORVBMJGJFEXJUIUIF TZTUFNQFSUIJTTUBOEBSE *&&&4UE6TFPGBOVORVBMJGJFECBUUFSZPSDIBSHFSNBZQSFTFOUBSJTLPG fire, explosion, leakage, or other hazard. t0OMZVTFUIFCBUUFSZGPSJUTPSJHJOBMQVSQPTF"TBOJNQSPQFSCBUUFSZVTFNBZSFTVMUJOBGJSF FYQMPTJPOPS other hazard. t5SZUPLFFQCBUUFSJFTJOBUFNQFSBUVSFCFUXFFO¡' ¡$ BOE¡' ¡$ *GUIFCBUUFSZJTTUPSFEJO temperatures above or below the recommended range, give it time to warm up or cool down before using. t4UPSFUIFEJTDIBSHFECBUUFSZJOBDPPM EBSL BOEESZQMBDF t1VSDIBTFBOFXCBUUFSZXIFOJUTPQFSBUJOHUJNFHSBEVBMMZEFDSFBTFTBGUFSGVMMZDIBSHJOH t1SPQFSMZBOEQSPNQUMZEJTQPTFPGUIFCBUUFSZBDDPSEJOHUPMPDBMMBXT t#BUUFSZVTBHFCZDIJMESFOTIPVMECFTVQFSWJTFE. 01. DON’TS. 08. 02 03 04 05 06 07. t Don’t attempt to disassemble or open the battery – it is a sealed unit with no serviceable parts. t Don’t crush, bend or deform, puncture or shred the battery. t Don’t drop the phone or battery. If the phone or battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection. t Don’t leave the battery in extremely hot or cold temperatures. Otherwise, it could significantly reduce the capacity and lifetime of the battery. t Don’t modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water PSPUIFSMJRVJET FYQPTFUPGJSF FYQMPTJPOPSPUIFSIB[BSE t Don’t accidentally short-circuit the battery by carrying it in your pocket or purse with other metallic objects such as coins, clips and pens. This may critically damage the battery. t Don’t short-circuit a battery or allow metallic conductive objects to contact battery terminals. t Don’t dispose of the battery by placing into a fire.. 21.

(13) BASIC OPERATION. 2. This chapter addresses and explains the basic features for HOTSHOTTM including: TURNING THE PHONE ON AND OFF USING THE TOUCHSCREEN USING THE HOME SCREEN LOCKING OR UNLOCKING THE TOUCHSCREEN AND KEYS USING THE TASK MANAGER MENU SUMMARY MAKING A CALL ANSWERING A CALL MISSED CALL NOTIFICATION WAIT/PAUSE FEATURE. MAKING AN INTERNATIONAL CALL 3-WAY CALLING CALL WAITING FUNCTION CALLING A NUMBER FROM CONTACTS ADJUSTING THE MASTER VOLUME SPEAKERPHONE MODE AVAILABLE OPTIONS DURING A CALL MAKING AN EMERGENCY CALL USING THE DIRECTORY SERVICE.

(14) TURNING THE PHONE ON AND OFF TURNING THE PHONE ON. Tap and hold: Tap an item and hold it for more than 2 seconds to perform functions.. 1. Press and hold the Power Key until the touchscreen turns on. 2. Enter your 4-digit lock code if the phone is locked. The default lock code is the last 4 digits of your phone number.. TURNING THE PHONE OFF. 01 Scroll: Tap and drag your finger up, down, left, or right to scroll through items in lists.. USING THE TOUCHSCREEN The touchscreen of your phone allows you to select items and perform functions. The following finger actions help you easily understand how to use the touchscreen. CAUTION: t Do not use sharp tools to avoid scratching the touchscreen. t Do not allow the touchscreen to come in contact with water or chemicals. The touchscreen may malfunction in humid conditions or in chemicals. t Do not sit on your phone to prevent from damaging the touchscreen.. Tap: Tap once to select or access a menu or an option.. 24. 03 04. 1. Press and hold the Power Key . 2. TURN OFF THE PHONE? is displayed. Tap Yes to turn the phone off. t Immediately change or recharge the battery when “BATTERY LOW” appears on the display. Memory may possibly be damaged if the phone turns off due to the battery completely draining. t Turn the phone off before removing or replacing the battery. If the phone is on, unsaved data may be lost.. 02. 05 Drag: Tap and hold your finger on an item and move your finger without losing contact with the screen to move the item.. 06 07 08. Drag and drop: Tap and drag your finger on an item to select and move it, then lift your finger to drop the item into place.. Swipe: Tap and drag your finger SFQFBUFEMZUPRVJDLMZNPWFUISPVHIB list or to another screen.. 25.

(15) USING THE HOME SCREEN. USING FAVORITE CONTACTS. Your phone’s home screen has three different screens which allow you to access main menus, multimedia shortcuts and favorite contacts. To access the home screen, unlock the screen and press the Home Key. To access another screen, tap the desired screen.. 'BWPSJUFDPOUBDUTBMMPXZPVUPRVJDLMZBDDFTTZPVSGBWPSJUFDPOUBDUT. ACCESSING A SHORTCUT ITEM 1. Unlock the screen. 2. From the Menu mode screen, swipe the screen left to move to the favorite contacts screen. 3. Tap the item you want to access.. ADDING CONTACTS 1. From the favorite contacts screen, tap and then tap . 2. Select a contact and tap Add. The selected contact is shown on the screen.. 01 02 03 04 05. DELETING CONTACTS. 06. 1. From the favorite contacts screen, tap . 2. Tap Remove . 3. Tap the contact to delete and then tap Remove.. 07 08. SETTING CONTACTS ACCESSING MENUS 1. To access Menu mode from the idle screen, unlock the screen. The Menu mode screen automatically appears. 2. Tap the menu you want. 3. Tap Back to move back one level. Press the Home Key to return to the Menu mode screen.. 1. From the favorite contacts screen, tap . 2. Tap Set . 3. Tap a contact. 4. Tap the desired option in the Change to field.. USING MULTIMEDIA SHORTCUTS .VMUJNFEJBTIPSUDVUTBMMPXZPVUPRVJDLMZBDDFTTZPVSGBWPSJUFJUFNTTVDIBT music, pictures, and videos.. ACCESSING A SHORTCUT ITEM 1. Unlock the screen. 2. From the Menu mode screen, swipe the screen right to move to the multimedia shortcut screen. 3. Tap the item you want to access.. 26. 27.

(16) ADDING AN ITEM. USING THE TASK MANAGER. 1. From the multimedia shortcut screen, tap . 2. Tap either My Music, My Pictures, My Videos or Shortcuts. 3. Select an item and tap Add. The selected item is shown on the screen.. You can manage multiple applications that are running at the same time. Switch to other applications without closing the current application you are using.. DELETING AN ITEM 1. From the multimedia shortcut screen, tap . 2. Tap Remove . 3. Tap the item to delete and then tap Remove. 4. Tap Yes to confirm.. 28. 1. Unlock the screen. 2. Press and hold the Home Key to open the Task Manager screen. The list of applications appears. 3. Use the following functions to control applications: t To switch to another application, tap the desired application from the list. t To close all applications, tap Close All. t To return to Menu mode, tap Main Menu. t To return to the previous menu, tap Back.. 01 02 03 04 05. LOCKING OR UNLOCKING THE TOUCHSCREEN AND KEYS. 06. When your phone is unlocked or idle, the touchscreen and keys are automatically locked to prevent any unwanted phone operations. To unlock, tap Drag up to unlock.. 07 08. 29.

(17) MENU SUMMARY 3RD Depth. 4TH Depth. Voicemail. Shop Ringtones My Ringtones. Music & Tones. Media Center. Picture & Video. My Music. My Sounds V CAST Videos Shop Pictures My Pictures My Videos Take Picture Record Video Online Album. Games Mobile Web Browse & Download Extras New Message Message. 30. Inbox Sent Drafts. 2ND Depth. Main Menu 2ND Depth. Main Menu. 3RD Depth. Mobile IM Play All Songs All Songs Playlists Artists Genres Albums Manage My Music Music Only Mode. Email. Contacts. Recent Calls. Tools. Text Message Picture Message Video Message Voice Message. In Case of Emergency Contact List Voicemail Directory Assistance My Name Card All Calls Missed Calls Received Calls Dailed Calls Voice Commands Calculator Tip Calculator Calendar Alarm Clock Stop Watch World Clock Unit Converter Notepad USB Mass Storage Airplane Mode Bluetooth Bluetooth Settings. Settings Sound Settings. 4TH Depth. Call Voicemail Clear Counter Mobile Email Mobile Web Mail Personal Info. 01 02 03 04 05 06 07 08. Bluetooth Radio Add New Devices Master Volume Ringtones Caller ID Readout Emergency Tone Alert Vibrate Alerts Reminder. 31.

(18) Main Menu. 2ND Depth. Display Settings. Touch Settings. 3RD Depth. Touch Vibrate Voice Commands Settings. Phone Settings. 4TH Depth. Power On/Off Sound Unlock Sound Service Alerts Touch Audio Feedback Digit Dial Readout Device Connect Wallpaper Banners Main Menu Settings Backlight Timer Backlight Brightness Display Theme Font Type Dial Fonts Menu Font Size Clock Format. 2ND Depth. Call Settings. Phone Memory Touch Vibrate Feedback Vibrate Level Confirm Choices Sensitivity Adapt Voice Prompts About. Edit Codes Restrictions Phone Lock Setting Lock Phone Now Restore Phone. System Select NAM Select. 3RD Depth. Auto NAM Change NAM. 4TH Depth. Home Key To Answer Auto Answer with Handsfree Auto Retry TTY Mode Voice Privacy DTMF Tones Assisted Dialing Save Options. Memory. Card Memory. Language Location Current Country. Security. 32. Main Menu. 01 02 03 Pictures Videos Sounds Phone Memory Usage My Pictures My Videos My Ringtones My Music My Sounds My Contacts Move All to Card Card Memory Usage My Pictures My Videos My Ringtones My Music My Sounds My Contacts Move All to Phone. 04 05 06 07 08. USB Mode. Phone Info. My Number SW/HW Version Icon Glossary Software Update. Status Check New. Operating System. 33.

(19) MAKING A CALL. TO DISPLAY A MISSED CALL ENTRY FROM RECENT CALLS:. 1. Unlock the screen and tap Keypad . 2. Enter an area code and a phone number.. 1. Unlock the screen and tap Recent Calls . 2. Tap Missed Calls. 3. Select an entry from the list. 4. To dial the phone number, tap . Or, to send a Text, Picture, Video or Voice Message to the caller, tap Send Message.. 01. WAIT/PAUSE FEATURE. 04. t To erase one digit at a time, tap . t To erase the entire number, tap and hold. .. 3. Tap to dial the number. To access menus during a call, press the Home Key. 4. To end the call, tap END. t If Auto Retry is set to on, the phone will automatically re-dial the number (Refer to page 76). t You can also make a call by using the Voice Commands feature. Please refer to page 51 for more details.. ANSWERING A CALL 1. When a call comes in, unlock the screen and tap ANSWER. t To ignore the incoming call, tap IGNORE. t To silence the call ringtone, tap QUIET.. 2. To end the call, tap END. If Auto Answer with Handsfree is set to on, an incoming call is answered automatically after a few seconds (Refer to page 76).. Wait (W) The phone pauses dialing and resumes dialing the next number when you tap .. 2-Sec Pause (P). When an incoming call is not answered, the missed call icon appears on the touchscreen.. The phone waits 2 seconds before sending the next string of digits automatically.. 1. Tap View Now. 2. To check the missed call notification at another time, tap View Later.. 03 05 06 07 08. 1. Unlock the screen and tap Keypad . 2. Enter a phone number. 3. Tap More and then tap Wait. 4. Enter the additional number(s). 5. Tap to dial or Save to save the number.. MISSED CALL NOTIFICATION TO DISPLAY THE MISSED CALL ENTRY FROM THE NOTIFICATION SCREEN:. 34. Pauses are used for automated systems (i.e., voicemail or calling cards). Insert a pause after a phone number and then enter another group of numbers. The second set of numbers is dialed automatically after the pause. This feature is VTFGVMGPSEJBMJOHJOUPTZTUFNTUIBUSFRVJSFBDPEF. 02. 1. Unlock the screen and tap Keypad . 2. Enter a phone number. 3. Tap More and then tap 2-Sec Pause. 4. Enter additional number(s) (pin number or credit card number). 5. Tap to dial or Save to save the number. 35.

(20) 2. To switch back to the first caller, tap SWAP CALLS. 3. To end all calls, tap END ALL CALLS.. MAKING AN INTERNATIONAL CALL 1. Unlock the phone and tap Keypad . 2. Tap and hold 5IF

(21) SFRVJSFEGPSJOUFSOBUJPOBMDBMMTBQQFBST 3. Enter the country code, area code, and phone number, then tap 4. To end the call, tap END.. .. 3-WAY CALLING With 3-Way Calling, you can talk to two people at the same time. When using this feature, normal airtime rates will be applied for each of the two calls.. 1. Unlock the phone and tap Keypad . 2. Enter a phone number and tap . 3. Once you have established the connection, tap Keypad and enter the second phone number you wish to call, and tap . 4. When you’re connected to the second party, tap MERGE CALLS to begin your 3-way call. 5. To end the last dialed call, tap END LAST DIALED CALL. To end all calls, tap END ALL CALLS. If one of the people you called hangs up during your call, you and the remaining caller stay connected. If you initiated the call and are the first to hang up, all three calls will be disconnected.. CALL WAITING FUNCTION If you are on a call and you receive another incoming call, you will hear a beep and the caller’s phone number will appear on the display. With Call Waiting, you may put the active call on hold while you answer the other incoming call.. CALLING A NUMBER FROM CONTACTS. 01. 1. With the phone unlocked, from the Menu mode, tap Contacts . 2. Tap the first letter of the contact name you want, or tap and scroll to a contact from the contact list. 3. Tap to dial the contact number.. 02. If the contact has more than two numbers, the default number of the contact will be dialed.. ADJUSTING THE MASTER VOLUME 1. With the phone unlocked screen, from the Menu mode, press the Volume Keys up or down . 2. Tap or , or press the Volume Keys up or down to adjust the volume level. To hear the phone’s volume, tap Play on the Master Volume menu. 3. Tap Set to save the setting.. 03 04 05 06 07 08. Press the Volume Keys up or down / to adjust the earpiece volume during a call.. SPEAKERPHONE MODE The Speakerphone feature lets you hear audio through the phone speaker and talk without holding the phone.. 1. During a call, tap Speaker to activate Speakerphone mode. 2. To deactivate Speakerphone mode, tap Speaker again.. 1. To answer another call while on the phone, tap HOLD CALL AND ANSWER INCOMING. This places the first call on hold. 36. 37.

(22) AVAILABLE OPTIONS DURING A CALL. USING THE DIRECTORY SERVICE. During a phone call, you can access the following options:. You can make a call to the directory service to find out your local numbers.. t Mute: Allows you to turn off your phone’s microphone so that the other person cannot hear you. t Speaker: Allows you to talk and hear through the phone’s speaker. t Bluetooth: Allows you to use the Bluetooth feature. t Keypad: Opens the dial screen.. 1. With the phone unlocked screen, from the Menu mode, tap Keypad 2. Enter “411” and tap .. .. 01 02 03. MAKING AN EMERGENCY CALL. 04. The E911 feature automatically places the phone in Emergency call mode when you dial the preprogrammed emergency number, “911.“ It also operates in Lock mode and out of the service area.. 05. E911 IN LOCK MODE. 07. When you lock the phone by using the Lock Phone Now setting (refer to page 74) or you are out of the service area, to make an emergency call:. 06 08. 1. When “Enter Code” appears, tap E911. 2. Tap Yes to dial. The phone maintains Emergency mode for about 5 minutes. When the call ends, the phone returns to Lock mode.. E911 USING ANY AVAILABLE SYSTEM To make an emergency call using any available system:. 1. With the phone unlocked screen, from the Menu mode, tap Keypad . 2. Enter “911” and tap . 3. The phone will stay in Emergency mode for about 5 minutes. While the phone is in Emergency mode you can receive an incoming call from any available system or you can make outgoing calls even in Emergency callback mode.. 38. 39.

(23) MEMORY FUNCTION. 3. This chapter addresses memory functions including:. ENTERING TEXT STORING A PHONE NUMBER EDITING CONTACT ENTRIES BACKUP ASSISTANTTM SENDING A NAME CARD SPEED DIALING.

(24) ENTERING TEXT. ENTERING TEXT USING INPUT MODES. You can enter text by using the virtual keypad on your touchscreen.. When entering text with the keypad, you can use the following modes:. CHANGING THE TEXT INPUT MODE. Mode. 1. In text entry mode, tap the Add Text field to display the virtual keypad. 2. Change the text input mode - see the chart below. 3. Tap the virtual keys to enter text.. T9 Word abc 123 Symbol. 4 5 6. 1 2 3 Number 1 2 3 4 5 6 42. Function Switches to T9 Word or ABC mode. When T9 Word mode is activated, the the upper left corner of the key turns red. Switches to Number mode. Inserts a space. Changes case. Switches to Symbol mode. Clears the entered characters.. Function 1. Tap the appropriate virtual keys to enter an entire word. 2. When the word displays correctly, tap Space to insert a space and enter the next word. If the correct word does not display, tap the pop-up window and select an alternate word. Tap the appropriate virtual keys until the character you want appears on the display. Tap the appropriate virtual keys to enter a number. Tap the appropriate virtual keys to enter a symbol.. 01 02 03 04 05. ENTERING TEXT USING THE VIRTUAL KEYBOARD. 06. You can enter text by using the virtual QWERTY Keyboard.. 07. 1. Tap the Add Text field. 2. Rotate the phone counter-clockwise to landscape view. The QWERTY Keyboard screen appears. 3. Enter text as you would use your computer’s keyboard.. 08. 3 4 5. 1 2 Number 1 2 3 4 5. Function Changes case. Switches to Number/Symbol mode. Clears the entered characters. Starts a new line. Inserts a space. 43.

(25) 4. Tap a group and then tap Done. To create a new group, tap New Group and then enter the name and tap Done. 5. Tap Save to update the contact entry.. STORING A PHONE NUMBER The Contact list stores up to 1000 entries.. ADDING A NEW CONTACT 1. With the phone unlocked screen, from the Menu mode, tap Keypad 2. Enter a phone number and tap Save. 3. Tap Add New Contact.. .. Use Update Existing to add another phone number to a contact that is already stored in memory.. 4. Select a number type (Mobile/Home/Business/Mobile 2/Fax). 5. Tap the Name field. 6. Enter the contact name and tap Done. 7. Enter additional contact information, if necessary. 8. Tap Save to save the contact. 9. The contact number re-appears on the screen, tap to dial the number.. EDITING A CONTACT Once the basic phone number and name information is stored in your Contacts, you can edit the contact information.. 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Tap the information field you want to edit. 4. Change the data as necessary, then tap Save to update the contact entry.. ADDING OR CHANGING GROUPS To organize your Contacts into groups:. 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Scroll down and tap the Group field. 44. CHANGING THE CALL RINGTONE To identify who is calling by setting different ringtones for different phone numbers in your Contacts:. 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Scroll down and tap the Ringtone field. 4. Select a ringtone by tapping the ringtone name in the Change to field. 5. Tap Save to update the contact entry.. 01 02 03 04 05 06. SETTING A PICTURE CALLER ID. 07. Picture caller ID displays the picture of the person calling when your phone rings. If the caller’s identity is stored with a picture in Contacts, the name and picture appear on the screen. To select a picture to assign to a contact:. 08. 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Tap the picture frame on the Name field. 4. Tap a picture. 5. Tap Set Picture ID. 6. Tap Save to update the contact entry.. ADDING AN EMAIL ADDRESS To add an email address to a contact entry:. 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Scroll down, and tap Personal Email or Business Email. 45.

(26) 4. Enter an email address and tap Done. 5. Tap Save to update the contact entry.. ADDING A SPEED DIAL ENTRY To add an entry to speed dial:. 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Scroll down and tap the Speed Dials field. 4. Tap the contact’s number you would like to assign, if applicable. 5. Enter the speed dial number you want to set and tap the entered number from the list. You can also tap. and select a speed dial number directly from the list.. 6. Tap Save update the contact entry.. EDITING CONTACT ENTRIES You can edit a contact by changing or deleting a phone number, name, and speed dial number.. EDITING A PHONE NUMBER FROM THE DIAL SCREEN 1. Unlock the screen and tap Keypad . 2. Enter the phone number you want to save (up to 32 digits) and tap Save. 3. Tap Update Existing. 4. Tap an existing contact entry. 5. Tap a number type. 6. If the number is already assigned to the type you selected, tap Yes to overwrite the existing entry. 7. Tap Save to update the contact entry.. 46. ADDING A PHONE NUMBER FROM THE CONTACT LIST 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Tap the number type you want to add. 4. Enter a phone number and tap Done. 5. Tap Save to update the contact entry.. EDITING A STORED PHONE NUMBER. 01 02 03. 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Tap the number type you want to edit. 4. Tap and hold and enter a new number, and tap Done. 5. Tap Save to update the contact entry.. 04. EDITING A STORED NAME. 08. 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Tap the Name field. 4. Tap and hold and enter a new name, and tap Done. 5. Tap Save to update the contact entry.. 05 06 07. DELETING A PHONE NUMBER FROM A CONTACT 1. Unlock the screen and tap Contacts . 2. Tap the desired contact and then tap Edit. 3. Select a number type to be deleted. 4. Tap and hold and tap Done to delete the number. 5. Tap Save to update the contact entry.. 47.

(27) DELETING A CONTACT ENTRY 1. Unlock the screen and tap Contacts 2. Tap the contact to be deleted. 3. Tap Erase and then tap Yes.. 5. Tap Add Recipient and select one of the following sending options: .. DELETING A SPEED DIAL NUMBER 1. Unlock the screen and tap Contacts . 2. Tap More and then tap Speed Dials. 3. Tap the speed dial number to be deleted. 4. Tap Remove and then tap Yes.. BACKUP ASSISTANTTM Backup AssistantTM is a wireless service that stores a copy of your Contact list to a secured website.. 1. Unlock the screen and tap Contacts . 2. Tap More and then tap Backup Assistant. 3. Follow the on-screen prompts.. SENDING A NAME CARD You can send a contact as the name card via message or Bluetooth.. tFrom Contacts tFrom Favorites tFrom Recent Calls tEnter Number tGroups. 6. Tap the desired recipient(s) and then tap Done. 7. Tap Send to send the contact as a name card via the selected sending option.. SPEED DIALING *EFBMGPSGSFRVFOUMZEJBMFEOVNCFST UIJTGFBUVSFBMMPXTDPOUBDUFOUSJFTUPCFEJBMFEWJB the virtual keypad with only one or two key taps. To open the dial screen from Menu mode, tap Keypad . t 2-9: Tap and hold the number you wish to connect to for more than 1 second.. 1 is already assigned for your voicemail box. t 10-94: Tap the first digit and tap and hold the second digit of the number to dial. t 95, 96, 97, 98 and 99: Speed Dial entries 95 (#Warranty Center), 96 (#DATA), 97 (#BAL), 98 (#MIN) and 99 (#PMT) are already assigned for Verizon Wireless Account Information. t 411: Speed Dial entry 411 (Directory Assistance) is already assigned.. 01 02 03 04 05 06 07 08. 1. Unlock the screen and tap Contacts . 2. Tap More and then tap Send Name Card. 3. Select one of the following sending options: tSend via Bluetooth: Allows you to send a name card via Bluetooth. tSend via Text Msg: Allows you to send a name card via Text Message. tSend via Picture Msg: Allows you to send a name card via Picture Message. tSend via Video Msg: Allows you to send a name card via Video Message. tSend via Voice Msg: Allows you to send a name card via Voice Message.. 4. Tap the desired contact(s) and then tap Done. 48. 49.

(28) MENU FUNCTION. 4. This chapter addresses accessing the menu and using its functions and features to customize your HOTSHOTTM RECENT CALLS MY VERIZON VOICE COMMANDS CALCULATOR TIP CALCULATOR CALENDAR ALARM CLOCK STOP WATCH. WORLD CLOCK UNIT CONVERTER NOTEPAD USB MASS STORAGE AIRPLANE MODE BLUETOOTH SOUND SETTINGS DISPLAY SETTINGS. TOUCH SETTINGS PHONE SETTINGS CALL SETTINGS MEMORY USB MODE PHONE INFO.

(29) RECENT CALLS The Recent Calls menu is a list of the recent phone numbers or Contact entries for calls you placed, accepted, missed, or blocked. It is continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list.. 01. BLOCKED CALLS. 02. MISSED CALLS. This menu appears only when incoming calls are restricted in the Restrictions menu.. Displays information about the most recently missed calls. Place a call to a missed call by simply tapping .. 1. Unlock the screen and tap Recent Calls 2. Tap More and then tap Blocked Calls. 3. Enter the 4-digit lock code.. 1. Unlock the screen, tap Recent Calls and then tap Missed Calls. 2. Tap the desired call log to view details or tap More to access the options by refering to All Calls. 3. Tap to dial, or tap Send Message to send a message to the number. If the number is not stored in Contacts, tap Save to Contacts to save the number.. RECEIVED CALLS Displays information about the most recently received calls. Place a call to a received call by simply tapping .. 1. Unlock the screen, tap Recent Calls and then tap Received Calls. 2. Tap the desired call log to view details or tap More to access the options by refering to All Calls. 3. Tap to dial, or tap Send Message to send a message to the number. If the number is not stored in Contacts, tap Save to Contacts to save the number.. DIALED CALLS Displays information about the most recently dialed numbers. Place a call to a dialed call by simply tapping .. 1. Unlock the screen, tap Recent Calls 48. 2. Tap the desired call log to view details or tap More to access additional options. 3. Tap to dial, or tap Send Message to send a message to the number. If the number is not stored in Contacts, tap Save to Contacts to save the number.. .. The default lock code is the last 4 digits of your phone number.. 4. Select a call log to view details.. ALL CALLS Displays information about all of the most recent calls you have received, dialed, and missed.. 03 04 05 06 07 08. 1. Unlock the screen, tap Recent Calls . The All Calls log is displayed. 2. Tap the desired call log to view details or tap More to access the following options: tSort by: Changes the sort order of call logs. tErase: Deletes a call log or multiple call logs. tErase All: Deletes all call logs. t View Timers: Allows you to view the call timers by call type. tBlocked Calls: Allows you to view blocked calls, if applicable.. 3. From the desired call log, tap to dial, or tap Send Message to send a message to the number. If the number is not stored in Contacts, tap Save to Contacts to save the number.. and then tap Dialed Calls. 49.

(30) MY VERIZON. CALL <NAME OR #>. My Verizon allows you to check your account information and get available Verizon services.. Use the Call command to voice dial a name from your Contacts or a phone number. When dialing a number, pronounce each digit, but do not pause noticeably between the digits.. 1. Unlock the screen and tap My Verizon . 2. When the phone is connected to the My Verizon page, follow the on-screen prompts.. VOICE COMMANDS :PVSQIPOFJTFRVJQQFEXJUIBO"EWBODFE7PJDF$PNNBOET "7$ GFBUVSF5IJTGFBUVSF allows you to make calls or use the phone’s functions by simply using your voice. All you have to do is to talk into the phone and then the phone will recognize your voice and perform tasks by itself.. 1. Unlock the screen, tap Tools. and then tap Voice Commands.. Shortcut : Unlock the screen and press the Voice Commands Key .. 2. The phone displays the Voice Commands menu and prompts you to say the name of the command you want to use. To complete your task, simply follow the voice prompts. You can speak the name of the command. 3. Say or select one of the following commands; Call <Name or #> / Send <MSG Type> / Go To <Menu> / Check <Item> / Contact <Name> / Redial / Play <Playlist> / My Verizon / Help. 50. 1. You will hear “Please say a command“ and the Voice Commands menu will be displayed. 2. If calling a contact from your Contact List, say “Call <Name>.” Your phone will ask you to confirm the name you said. Say “Yes“ if it was repeated correctly. That phone number will be dialed. If there is more than one number saved for that contact, you will be asked to confirm which number to dial. Examples: Call John Work. SEND <MSG TYPE> Use the Send command to send a text or other type of message to a specified name or number.. 1. You will hear “Please say a command“ and the Voice Commands menu will be displayed. 2. Say “Send“ followed immediately by one of the following items: Text / Picture / Video / Voice 3. Say the desired contact or group name, or the number of the message recipient.. 01 02 03 04 05 06 07 08. GO TO <MENU>. To view information about each option, tap Info. Tap Settings to access voice commands settings. Please refer to page 70 for more details on Voice Commands Settings.. Use the Go To command to open an application on your phone. You can say “Go To” by itself and be prompted to say the application name, or you can skip the prompt by saying ”Go To” followed by the application name.. 4. When it recognizes one of these commands, the phone launches the associated application. If the phone does not hear a command within a specified time, Voice Commands will turn itself off.. 1. You will hear “Please say a command“ and the Voice Commands menu will be displayed. 2. Say “Go To” followed immediately by one of the menus in the list. Examples: “Go To Calendar”. If no menu option is stated, a list of options will be provided. 51.

(31) CHECK <ITEM>. PLAY <PLAYLIST>. The Check command lets you check status information for your phone. You can say “Check” or “Check Status” to see and hear all status information.. Say “Play” followed by a playlist title and then your phone will play back the recognized playlist for you.. 1. You will hear “Please say a command“ and the Voice Commands menu will be displayed. 2. Say “Check” followed immediately by one of the following items: Status / Voicemail / Messages / Missed Calls / Time / Signal Strength / Battery Level / Volume / Balance / Minutes / Payment / My Number. 1. You will hear “Please say a command“ and the Voice Commands menu will be displayed. 2. Say “Play <Playlist>” to play back individual playlist or say “Play All Songs” to play back all songs saved in your phone.. 01. CONTACT <NAME>. MY VERIZON Use the My Verizon command to access information about your Verizon account.. 04. Use the Contact command to retrieve and display information for any name stored in your Contact List.. 1. You will hear “Please say a command“ and the Voice Commands menu will be displayed. 2. Say “My Verizon.” Your phone will make a web connection.. 1. You will hear “Please say a command“ and the Voice Commands menu will be displayed. 2. Say “Contact <Name>” to retrieve and display the contact information: Call / Readout / Create New / Modify / Erase Examples: Contact Bob Smith and follow the voice prompts.. REDIAL. HELP Use the Help command to view how to use the Voice Commands.. 02 03 05 06 07 08. 1. You will hear “Please say a command“ and the Voice Commands menu will be displayed. 2. Say “Help.” The Help guide will be displayed on your phone.. Use the Redial command to make a call to the last number you dialed.. 1. You will hear “Please say a command“ and the Voice Commands menu will be displayed. 2. Say “Redial.” Your phone will make a call to the last number you dialed.. CALCULATOR The Calculator allows you to perform simple mathematical calculations. To access the calculator:. 1. Unlock the screen, tap Tools and then tap Calculator. 2. Use the virtual keys that correspond to the calculator display to perform basic mathematical operations. 3. To reset the calculator, tap Clear All.. 52. 53.

(32) TIP CALCULATOR Allows you to calculate the tip and determine how much each person should pay for the bill.. 1. Unlock the screen, tap Tools and then tap Tip Calculator. 2. Enter the amount in the Total Bill field by using the number keypad. 3. Scroll to the percentage of tip in the % Tip field. The amount of a tip will be displayed in the Tip ($) field. 4. Scroll to the number of attendees in the People field. The amount per each person is shown in the Each field. 5. To reset the tip calculator, tap Reset.. 6. Tap Save to save the event. The date of the event will be marked as the black triangle on your calendar.. VIEWING AN EVENT 1. Unlock the screen, tap Tools and then tap Calendar. 2. Tap a date with a scheduled event. 3. Tap an event to view details.. CALENDAR. DELETING AN EVENT. The Calendar tool provides easy and convenient access to your schedule. Simply store your appointments and your phone will alert you.. 1. Unlock the screen, tap Tools and then tap Calendar. 2. Tap a date with a scheduled event. 3. Tap an event to be deleted. 4. Tap More and then tap Erase. 5. Tap Yes to confirm.. CREATING A NEW EVENT 1. Unlock the screen, tap Tools and then tap Calendar. 2. Tap New. 3. Tap the Subject field. 4. Enter the subject and tap Done. 5. Enter the event information by using the following options: tStart Date: Enter the starting date of the event. tStart Time: Enter the starting time of the event. tEnd Date: Enter the ending date of the event. tEnd Time: Enter the ending time of the event. tRecurrence: Sets the recurrence of the event (None/Daily/Every X Days/Weekly/Monthly/ Yearly). tAlert Tone: Selects a ringtone for the event alarm. tVibrate: Sets the phone to vibrate for alerting you to the event.. 54. tAlert Time: Sets the alert time before the event takes place (On Time/15 minutes before/30 minutes before/45 minutes before/1 hour before/3 hours before/5 hours before/1 day before). tReminder: Sets the phone to remind you of the event (Off/Once/Every 2 minutes/Every 15 minutes).. 01 02 03 04 05 06 07 08. DELETING ALL EVENTS 1. Unlock the screen, tap Tools and then tap Calendar. 2. Tap More and then tap Erase All. 3. Tap Yes to confirm.. DELETING ALL PAST EVENTS Allows you to delete all past events from today.. 1. Unlock the screen, tap Tools and then tap Calendar. 2. Tap More and then tap Erase All Old. 3. Tap Yes to confirm.. 55.

(33) ALARM CLOCK. RESETTING ALL ALARM SETTINGS. The Alarm Clock tool allows you to set up to three alarms. When you set an alarm, the current time is displayed at the top of the screen. When the alarm goes off, ALARM will be displayed on the screen and the alarm will sound.. 1. Unlock the screen, tap Tools 2. Tap Reset All. 3. Tap Yes to confirm.. SETTING AN ALARM 1. Unlock the screen, tap Tools 2. Tap an alarm (1, 2, or 3). 3. Set the following options:. and then tap Alarm Clock.. tSet Time: Sets the alarm time. tRepeat4FMFDUTBOBMBSNGSFRVFODZ Once / Daily / Mon - Fri / Weekends). tRingtone: Selects a ringtone for the alarm.. 4. Tap Save to save the alarm. The Alarm icon appears on the Menu mode display area.. STOPPING AN ALARM When an alarm sounds, tTap Snooze to delay the alarm for an additional 5 minutes. tTap Dismiss to stop the alarm.. DEACTIVATING AN ALARM 1. Unlock the screen, tap Tools and then tap Alarm Clock. 2. Tap ON next to the alarm you want to deactivate. You will see the indicator slide to OFF.. RESETTING AN ALARM SETTING 1. Unlock the screen, tap Tools 2. Tap an alarm to reset. 3. Tap Reset. 4. Tap Yes to confirm.. 56. and then tap Alarm Clock.. and then tap Alarm Clock.. STOP WATCH Simultaneously times up to twenty different events. To operate the stopwatch:. 01 02 03. 1. Unlock the screen, tap Tools and then tap Stop Watch. 2. Tap Start to start the stopwatch. 3. Tap Lap to record lap times. 4. Tap Stop to the stop recording lap times. 5. Tap Resume to restart recording lap times or tap Reset to clear recorded times.. 04. WORLD CLOCK. 08. World Clock allows you to view the time in another country and city.. 05 06 07. VIEWING WORLD CLOCKS 1. Unlock the screen, tap Tools and then tap World Clock. 2. Scroll through the world map and tap a continent. 3. Tap a city. You can also select a city from the list by tapping Cities.. SETTING DAYLIGHT SAVING TIME (DST) 1. Unlock the screen, tap Tools and then tap World Clock. 2. Scroll through the world map and tap a continent. 3. Tap a city. You can also select a city from the list by tapping Cities. 4. Tap DST to set the city as Daylight Saving Time.. 57.

(34) 3. Tap Yes to confirm.. UNIT CONVERTER The Unit Converter allows you to convert units of measurement from one to another.. 1. Unlock the screen, tap Tools and then tap Unit Converter. 2. Scroll up or down to select the measurement and units of the measurement in the appropriate fields. 3. Enter the value you want to convert from in the From field. As you enter the value, the converted value is shown in the To field.. NOTEPAD Your phone includes an internal notepad that can be used to compose and store reminders and notes.. CREATING A NEW NOTE 1. Unlock the screen, tap Tools and then tap Notepad. 2. Tap Yes to create a new note. If there are already saved notes, tap New. 3. Enter the note text and tap Done.. VIEWING A NOTE. USB MASS STORAGE USB Mass Storage allows you to transfer files to or from your PC. In order to use this function, you must insert a microSDTM card. Use this function with the 2GB microSDTM card that is pre-installed in your phone.. 01. 1. Connect your phone to a PC with the USB cable. 2. Unlock the screen, tap Tools and then tap USB Mass Storage. 3. When a pop-up window appears on your PC, open a folder to view files. 4. Copy files from the PC to the memory card.. 03. AIRPLANE MODE. 06. In Airplane mode, all menu functions can be accessed except making calls, receiving calls, data connection and Bluetooth®. Activating Airplane mode will disable all wireless communications including Location service.. 07. 02 04 05. 08. 1. Unlock the screen and tap Settings . 2. Tap OFF next to Airplane Mode. You will see the indicator slide to ON.. 1. Unlock the screen, tap Tools and then tap Notepad. 2. Tap the desired a note to view details.. DELETING A NOTE 1. Unlock the screen, tap Tools and then tap Notepad. 2. Tap next to the note you want to delete. 3. Tap Yes to confirm.. DELETING ALL NOTES To delete all saved memos:. 1. Unlock the screen, tap Tools 2. Tap Erase All. 58. and then tap Notepad.. 59.

(35) BLUETOOTH Bluetooth® technology connectivity enables wireless connections between electronic devices. If connected with a Bluetooth handsfree device, you can use your phone more freely. Since devices with Bluetooth connectivity communicate using radio waves, your phone and the other device do not need to be in direct line-of-sight. The two devices only need to be within 10 meters (30 feet) of each other. The connection can be subject to interference from obstructions such as walls or other electronic devices. This device is compliant with Bluetooth specification 3.0, supporting the following profiles: Dial Up Networking, Handsfree, Headset, Sync, Basic Imaging, Basic Printing, File Transfer, Object Push for vCard, Phonebook Access and Stereo. To ensure interoperability between other devices supporting Bluetooth technology, use approved enhancements for this model. Check with the manufacturers of other devices to determine their compatibility with this phone. There may be restrictions on using Bluetooth technology in some locations. Check with your local authorities or Verizon Wireless. If you want more information on this function, visit the Bluetooth Technology organization Web site: https://www.bluetooth.org/. Important: Features using Bluetooth technology, or allowing such features to run in the background while using other features, increase the demand on battery power and reduce the battery life.. TURNING ON THE BLUETOOTH FEATURE 1. Unlock the screen and tap Settings . 2. Tap OFF next to Bluetooth. You will see the indicator slide to ON.. ADDING A NEW DEVICE. Pairing is the process that allows your phone to locate, establish and register a 1-to-1 connection with the target device.. 1. Unlock the screen, tap Settings and then tap Bluetooth Settings. 2. Tap Add New Devices. 3. The phone will prompt you with the following message on the screen: “Place device you are connecting to in discoverable mode.” Tap Next. 60. 4. The device will appear in the Searching for Bluetooth devices... menu. Tap the device you wish to pair with and tap Pair Device. 5. The handset may prompt you for the passkey. Consult the Bluetooth accessory (sold separately) instructions for the appropriate passkey (typically “0000”— 4 zeroes). Enter the passkey and tap Done. tYou may not need to input the passkey for pairing when the passkey of the Bluetooth headset or hands-free kit is 0000. t*GUIF#MVFUPPUIWFSTJPOPGZPVSIFBETFUJTUIFTBNFBTZPVSQIPOFT#MVFUPPUI version, tap Yes without entering the passkey.. 01 02 03 04. 6. Tap Always Ask Before Connect if you want the phone to ask you before connecting to the device. 7. Once connected, you will see the device listed in the Bluetooth Settings menu.. 05. TRANSFERRING FILES. 07. 1. Unlock the screen, tap Settings and then tap Bluetooth Settings. 2. Tap the paired device in the list. 3. With Discovery Mode On for the paired device, select one of the following options:. 06 08. tSend Name Card: Allows you to send a contact as the name card. tSend Picture: Allows you to send photos to the device. tSend Video: Allows you to send videos to the device. tSend Calendar Event: Allows you to send calendar events to the device. tGet Name Card: Allows you to get name cards from the device. tExchange Name Card: Allows you to send your name card and receive a name card from the device. tBrowse/Get Files: Allows you to search and get files from the device.. 4. Tap the desired file(s) to transfer to or from the device and tap Done, if necessary.. 61.

(36) BLUETOOTH SETTINGS MY PHONE NAME To edit the Bluetooth® name of your phone:. 1. Unlock the screen, tap Settings and then tap Bluetooth Settings. 2. Tap Settings. 3. Tap My Phone Name. 4. Tap and hold and enter a name. 5. Tap Done to save the name.. DISCOVERY MODE To set whether your device is able to be searched for by other Bluetooth devices in the area:. 1. Unlock the screen, tap Settings and then tap Bluetooth Settings. 2. Tap Settings. 3. Tap OFF next to Discovery Mode. You will see the indicator slide to ON. If Bluetooth is not on, it will be turned on automatically.. SUPPORTED PROFILES To view brief descriptions of the profiles supported by the phone:. 1. Unlock the screen, tap Settings and then tap Bluetooth Settings. 2. Tap Settings. 3. Tap Supported Profiles. 4. Scroll to the profile information you want to view.. AUTO PAIR HANDSFREE To set your phone to pair with a handsfree device automatically:. SOUND SETTINGS Allows you to customize the sound settings of your phone.. MASTER VOLUME 1. Unlock the sceen, tap Settings and then tap Sound Settings. 2. Tap the volume level below Master Volume. 3. Tap or to adjust the volume level. To hear the volume level, tap Play. 4. To set to vibrate when your phone rings, tap OFF next to Vibrate While Ringing. You will see the indicator slide to ON. 5. Tap Set.. RINGTONES 1. Unlock the sceen, tap Settings and then tap Sound Settings. 2. From the Ringtones menu, select one of the following settings: tIncoming Call: Selects a ringtone for incoming calls. tText Msg.: Selects a ringtone for new text messages. tMultimedia Msg.: Selects a ringtone for new picture or video messages. tVoicemail: Selects a ringtone for new voicemails. tMissed Call: Selects a ringtone for missed call notifications.. 01 02 03 04 05 06 07 08. 3. To play a ringtone, tap the Key. 4. To select a ringtone, tap the name of the tone in the Change to field.. CALLER ID READOUT 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. Scroll down and tap the option next to Caller ID Readout. 3. Tap an option in the Change to field to select.. 1. Unlock the screen, tap Settings and then tap Bluetooth Settings. 2. Tap Settings. 3. Tap OFF next to Auto Pair Handsfree. You will see the indicator slide to ON. 62. 63.

(37) EMERGENCY TONE 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. Scroll down and tap Off next to Emergency Tone. 3. Tap an alert type in the Change to field to select.. ALERT VIBRATE Allows you to set the phone to vibrate when calls or messages come in.. 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. From the Alert Vibrate menu, tap OFF next to the setting you want to change to ON.. ALERTS REMINDER Allows you to set the phone to remind you of new messages and missed calls.. 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. From the Alerts Reminder menu, tap Off next to the setting you want to change. 3. Tap a reminder option in the Change to field to select.. POWER ON/OFF SOUND Allows you to set the phone to play sounds when the phone is turned on and off.. 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. Scroll down, then tap ON or OFF next to Power On or Power Off.. tERI: Allows you to set the phone to sound when the phone is connected to the network, calls are connected, or the service is not available. tMinute Beep: Allows you to set the phone to sound every minute during a call. tCall Connect: Allows you to set the phone to sound when an outgoing call is connect. tSoftware Update: Allows you to set the phone to sound when your phone’s software is updated.. 01. 3. Tap ON or OFF next to the desired option to adjust to the other setting.. 02. TOUCH AUDIO FEEDBACK. 03. Allows you to set the phone to play sounds when you tap the touchscreen.. 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. Tap ON or OFF next to Touch Audio Feedback.. DIGIT DIAL READOUT Allows you to set the phone to read digits when you enter a phone number from the dial screen.. 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. Scroll down and tap OFF next to Digit Dial Readout. You will see the indicator slide to ON.. 04 05 06 07 08. DEVICE CONNECT 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. Scroll down, then tap ON or OFF next to Device Connect.. UNLOCK SOUND Allow you to set the phone to play sound when the phone is unlocked.. 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. Scroll down, then tap ON or OFF next to Unlock.. SERVICE ALERTS 1. Unlock the screen, tap Settings and then tap Sound Settings. 2. From the Service Alerts menu, select one of the following settings: 64. 65.

(38) DISPLAY SETTINGS Allows you to customize the display of your touchscreen.. WALLPAPER. 3. Drag a item to new grid position. 4. Tap Save to save the desired Main Menu layout.. REPLACE MENU ITEMS. 01. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down to Main Menu Settings and then tap Replace Menu Items. 3. Tap a item to be replaced and then select new menu item. 4. Tap Save to save the desired Main Menu layout.. 02. BANNERS. CHANGE MENU LAYOUT. 05. To set your Personal or ERI banner:. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down to Main Menu Settings and then tap Change Menu Layout. 3. Tap a menu layout in the Change to field to select. 4. Tap Set As Menu Layout and then tap Yes.. 06. To select a wallpaper to be displayed on the phone:. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Tap the name of the current wallpaper in the Wallpaper field. 3. Tap the picture you want to change. 4. Tap Set As Wallpaper.. PERSONAL BANNER The Personal Banner can be up to 16 characters and is displayed on your phone’s display screen from idle mode.. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Tap None next to Personal. 3. Enter the banner text (up to 16 characters) and tap Save.. ERI BANNER If you use ERI Service, ERI text is shown on the sub banner.. 1. Unlock the screen, tap Settings 2. Tap OFF or ON next to ERI.. and then tap Display Settings.. MAIN MENU SETTINGS To change Main Menu layout and type:. POSITION MENU ITEMS. 03 04. 07 08. RESET MENU SETTINGS 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down to Main Menu Settings and then tap Reset Manu Settings. 3. Tap a option in the Reset to default field to select. 4. Tap Yes to confirm.. BACKLIGHT TIMER To set the duration of the backlight:. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down and tap the option next to Backlight Timer. 3. Tap a backlight time in the Change to field to select.. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down to Main Menu Settings and then tap Position Menu Items. 66. 67.

(39) BACKLIGHT BRIGHTNESS. MENU FONT SIZE. To adjust the brightness of the backlight:. To set the menu font size:. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down and tap the option next to Backlight Brightness. 3. To adjust the brightness automatically, tap OFF in the Auto Brightness menu. To adjust the brightness manually, tap the brightness level you want to change. 4. Tap Done.. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down and tap the option next to Menu Font Size. 3. Tap a font size in the Change to field to select.. DISPLAY THEME To choose the background screen:. 1. Unlock the screen, tap Settings. and then tap Display Settings.. The default display theme is White.. 2. Scroll down and tap the option in the Display Theme. 3. Tap a theme in the Change to field to select. 4. Tap Set As Display Theme.. FONT TYPE To set the font type:. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down and tap the option next to Font Type. 3. Tap a font type in the Change to field to select.. CLOCK FORMAT To set the clock type to be displayed on the idle screen:. 01 02 03. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down and tap the option next to Clock Format. 3. Tap a clock format in the Change to field to select. 4. Tap Set Clock Format.. 04. TOUCH SETTINGS. 07. Allows you to set the phone to vibrate when you touch the screen and set the vibration level.. 08. 05 06. 1. Unlock the screen, tap Settings and then tap Touch Settings. 2. Tap OFF or ON next to Touch Vibrate Feedback. 3. If you set to ON, tap the option next to Vibrate Level. Tap a vibrate level in the Change to field to select.. DIAL FONTS To set the dial font size:. 1. Unlock the screen, tap Settings and then tap Display Settings. 2. Scroll down and tap the option next to Dial Fonts. 3. Tap a font size in the Change to field to select.. 68. 69.

(40) PHONE SETTINGS Allows you to customize the phone settings of your phone.. VOICE COMMANDS SETTINGS Allows you to set options for Voice Commands.. CONFIRM CHOICES When the phone does not recognize your voice command, it will ask you to repeat your voice command. If it does not recognize the name or number, it will display a list of up to three choices and speak each one in turn. You can control how often the phone asks you to confirm the recognized name or number.. 1. Unlock the screen, tap Settings and then tap Phone Settings. 2. Tap Voice Commands Settings and then tap Confirm Choices. To view information about each option, tap Info.. 3. Tap a confirmation choice in the Change to field to select.. SENSITIVITY The Sensitivity setting allows you to adjust the sensitivity monitoring of voice tones. *GZPVGSFRVFOUMZFYQFSJFODFUIFNFTTBHFTiPlease try again” or “COMMAND NOT RECOGNIZED Try again?”, adjust the sensitivity toward Less Sensitive. If you GSFRVFOUMZFYQFSJFODFGBMTFBDUJWBUJPOT XIFOUIFQIPOFSFDPHOJ[FTBOBNFZPV didn’t say), adjust the sensitivity toward More Sensitive.. 1. Unlock the screen, tap Settings and then tap Phone Settings. 2. Tap Voice Commands Settings and then tap Sensitivity. 3. Tap Automatic, More Sensitive, or Less Sensitive in the Change to field to select.. ADAPT VOICE Voice Commands are speaker independent, which means that no training PSBEBQUBUJPOJTSFRVJSFE4PNFVTFSTXJUIIFBWZBDDFOUTPSVOVTVBMWPJDF characteristics may find difficulty in achieving high accuracy with speaker 70. independent Voice Commands, so the Adapt Voice feature allows users to dramatically improve the recognition accuracy after adapting their voices. Users who get acceptable recognition accuracy will find no additional benefit to performing the Adapt Voice feature.. 1. Unlock the screen, tap Settings and then tap Phone Settings. 2. Tap Voice Commands Settings and then tap Adapt Voice. 3. Tap Train Voice. tTrain Voice3FRVJSFTUIBUZPVNBLFSFDPSEJOHTPGZPVSWPJDFUPDVTUPNJ[FUIFWPJDF recognition system. It will take a few minutes. tReset Voice: Once you finish the adaptation process, you can reset the adaptation to the factory default. The Reset Voice option only appears after you finish the Train Voice process.. 4. Tap OK to begin. 5. Wait for the beep, and then repeat the sentences using a normal tone of voice. 6. When you are finished with a full session, you will reach a screen that reads “Adaptation complete.”. 01 02 03 04 05 06 07 08. PROMPTS Allows you to select voice command system characteristics.. 1. Unlock the screen, tap Settings and then tap Phone Settings. 2. Tap Voice Commands Settings and then tap Prompts. 3. Tap one of the following options and then tap the desired submenu option in the Change to field to select: t Mode: Tap the voice command system mode from the following: - Prompts'PSIBOETFUUPQSPNQUGPSSFRVJSFEJOGPSNBUJPO - Tones Only: For handset to provide beeps only for audio guidance. t Audio Playback: Allows audio playback to play through the speakerphone or earpiece. Tap Speakerphone or Earpiece. t Timeout: Tap a period of time either 5 seconds or 10 seconds which the system listens for a command before timing out.. 71.
