MODULO IV: ASEO URBANO:

SERVICIO DE TRATAMIENTO Y DISPOSICIÓN FINAL DE

RESIDUOS

UNIDAD I: APROVECHAMIENTO Y TRATAMIENTO DE RESIDUOS

SÓLIDOS

POR: ING. SERGIO NAVA

ORELLANA

(2)

CONTENIDO TEMATICO

  Aprovechamiento de  residuos sólidos.



Objetivo dfel aprovechamiento

Aprovechamiento de residuos sólidos implementando recolección diferenciada

Aprovechamiento de residuos orgánicos

Tratamiento de  residuos sólidos

Tratamiento termico

Tipos de plantas en el mercado aplkicables a nuestro medio

*La Unidad se limita en su desarrollo académico en: la instalación de recuperación de materiales reciclable, componentes de las plantas de recuperación, operación de la planta de

recuperación de materiales

(3)

APROVECHAMIENTO

El aprovechamiento es el conjunto de

actividades dirigidas a efectuar la

recolección, transporte y separación de

residuos sólidos, que seran sometidos a procesos de reciclaje compostaje,

lombricultora, biodigestión,

aprovechamiento energético u otro.

Aprovechamiento  de residuos

sólidos

Reciclables Recuperación de material

reciclable

Orgánicos

Compostaje y lombricultura

Indigestión Aprovechamiento

energético

(4)

OBJETIVO DEL APROVECHAMIENTO

 Racionalizar el uso y consumo de las materias primas provenientes de los recursos naturales no renovables.

 Recuperar valores económicos y energéticos utilizados en los diferentes procesos productivos.

 Reducir residuos sólidos que van a disposición final.

 Disminuir los impactos ambientales, tanto por demanda y uso de materias primas como por los procesos de disposición final.

 Garantizar la participación de los recuperadores de oficio, en las actividades de recuperación, aprovechamiento y

valorización.

(5)

Aprovechamiento de Residuos Sólidos

Implementando Recolección Diferenciada

Recolecció n

diferenciad a

Puede ser realizada mediante:

• Acuerdos del municipio con organizaciones recuperadores.

• Los medios de la entidad prestadora del SAU.

• Formulas mixtas

Los modelos de

separación en origen y recolección

diferenciada dependen de las caracteristicas locales del

municipio.

Para la separación puede implementar la clasificación:

• En 2 fracciones (orgánico y el resto de residuos)

• En 3 (orgánico, reciclables y resto no aprovechable) Para la separación puede implementar la clasificación:

• En 2 fracciones (orgánico y el resto de residuos)

• En 3 (orgánico, reciclables y resto no aprovechable)

(6)

Aprovechamiento de Residuos Sólidos

Implementando Recolección Diferenciada

Las campañas de

comunicación social deben ser muy

intensas para que estos

centros tengan éxito.

Esta iniciativa, la cual la denominaremos

“centros de acopio municipales”, necesita procesos de

concientización y vigilancia.

Esta iniciativa, la cual la denominaremos

“centros de acopio municipales”, necesita procesos de

concientización y vigilancia.

Centros de Acopio  Municipales

A nivel nacional, las personas que operan estos centros de acopio (acopiadores), son un

grupo de microempresas formales e informales y

personas naturales.

A nivel de manejo municipal, como ejemplo Cochabamba

se emplean los “puntos verdes” en diferentes barrios.

Son lugares donde reunir productos, desechados o

descartados por el consumidor al final de su vida

útil.

(7)

DESVENTAJAS:

- En los hogares se requieren varios

recipientes, que demanda mayor disposición de la población

- Exige constante limpieza en los centros - Los costos son elevados cuando el municipio realiza la recolección.

VENTAJAS:

- Costos menores de recolección - Los productos recolectados ahí son llevados directamente a la planta de aprovechamiento

- Pueden estar en un solo lugar en los municipios pequeños o distribuidos

estratégicamente en los municipios grandes

(8)

Requisitos para que los Residuos Sólidos sean Aprovechados

Óptimamente

Para la reutilización y reciclaje, los residuos sólidos deben estar limpios y debidamente seleccionados por tipo de material y característica físicas.

Para el compostaje y lombricultura no deben estar

contaminados con residuos peligrosos, metales pesados.

Con base en estudios de mercado y el potencial de comercialización, se deben definir los procesos de adecuación y transformación que van a ser llevados a cabo

(9)

Aprovechamiento de Residuos Orgánicos

Proceso termofílico, de degradación anaerobia (sin oxígeno) de la materia orgánica con la obtención final de una mezcla gaseosa conocida como biogás

consiste en la utilización de lombrices para la obtención de humus que es un abono

natural a partir de restos de materia orgánica Descomposición biológica aerobia de los

constituyentes orgánicos de los residuos sólidos.

Compostaj e Compostaj

e

Biodigestió n (Aprovecha

miento Energético) Biodigestió

n (Aprovecha

miento Energético)

Lombricultu ra Lombricultu

ra

(10)

TRATAMIENTO DE RESIDUOS

SÓLIDOS

Conjunto de operaciones

encaminadas a la

transformación física,

química, térmica o biológica

de los residuos sólidos

para el aprovechamiento de

los recursos contenidos en

ellos o para reducir la

peligrosidad de los mismos.

(11)

Tratamiento térmico para toda la fracción de los

residuos sólidos

Proceso térmico de residuos en ausencia total de oxígeno utiliza una fuente de combustible externa para conducir las reacciones en un ambiente libre de

oxígeno Procesamiento

térmico sin oxígeno en la cámara de reacción, transforman residuos en gas de síntesis.

Proceso de

reducción de los residuos sólidos a material inerte y a productos

oxidados mediante la combustión

Incineració n Incineració

n

Pirolisis/

termólisis Pirolisis/

termólisis Gasificaci ón Gasificaci

ón
