Abstract

This doctoral thesis explores some of the possibilities that near-field optics can bring to photovoltaics, and in particular to quantum-dot intermediate band solar cells (QD-IBSCs). Our main focus is the analytical optimization of the electric field distribution produced in the vicinity of single scattering particles, in order to produce the highest possible absorption enhancement in the photovoltaic medium in their surroundings. Near-field scattering structures have also been fabricated in laboratory, allowing the application of the previously studied theoretical concepts to real devices.

We start by looking into the electrostatic scattering regime, which is only applicable to sub-wavelength sized particles. In this regime it was found that metallic nano-spheroids can produce absorption enhancements of about two orders of magnitude on the material in their vicinity, due to their strong plasmonic resonance. The frequency of such resonance can be tuned with the shape of the particles, allowing us to match it with the optimal transition energies of the intermediate band material. Since these metallic nanoparticles (MNPs) are to be inserted inside the cell photovoltaic medium, they should be coated by a thin insulating layer to prevent electron-hole recombination at their surface.

This analysis is then generalized, using an analytical separation-of-variables method implemented in Mathematica7.0, to compute scattering by spheroids of any size and material. This code allowed the study of the scattering properties of wavelength- sized particles (mesoscopic regime), and it was verified that in this regime dielectric spheroids perform better than metallic. The light intensity scattered from such dielectric spheroids can have more than two orders of magnitude than the incident intensity, and the focal region in front of the particle can be shaped in several ways by changing the particle geometry and/or material.

Experimental work was also performed in this PhD to implement in practice the concepts studied in the analysis of sub-wavelength MNPs. A wet-coating method was developed to self-assemble regular arrays of colloidal MNPs on the surface of several materials, such as silicon wafers, amorphous silicon films, gallium arsenide and glass. A series of thermal and chemical tests have been performed showing what treatments the nanoparticles can withstand for their embedment in a photovoltaic medium. MNPs

(12)

arrays are then inserted in an amorphous silicon medium to study the effect of their plasmonic near-field enhancement on the absorption spectrum of the material.

The self-assembled arrays of MNPs constructed in these experiments inspired a new strategy for fabricating IBSCs using colloidal quantum dots (CQDs). Such CQDs can be deposited in self-assembled monolayers, using procedures similar to those developed for the patterning of colloidal MNPs. The use of CQDs to form the intermediate band presents several important practical and physical advantages relative to the conventional dots epitaxially grown by the Stranski-Krastanov method. Besides, this provides a fast and inexpensive method for patterning binary arrays of QDs and MNPs, envisioned in the theoretical part of this thesis, in which the MNPs act as antennas focusing the light in the QDs and therefore boosting their absorption.

(13)

Resumen

Esta tesis doctoral explora las posibilidades que la óptica de campo cercano puede traer a la tecnología fotovoltaica y, en particular, a las células solares de banda intermedia con puntos cuánticos (del inglés, QD-IBSCs). El enfoque principal es la optimización analítica de la distribución de campo eléctrico alrededor de partículas aisladas dispersoras de luz, para producir el mayor incremento posible de la absorción en el medio fotovoltaico que rodea estas partículas. Las estructuras de dispersión de campo cercano se han fabricado en laboratorio, permitiendo la aplicación en dispositivos reales de los conceptos teóricos estudiados.

En primer lugar se examina el régimen de dispersión electrostático, sólo aplicable a partículas con un tamaño inferior a la longitud de onda. En este régimen se ha determinado que nano-esferoides metálicos pueden producir mejoras de hasta dos órdenes de magnitud en la absorción del material que los rodea, debido a su fuerte resonancia plasmónica. La frecuencia de la resonancia puede ajustarse variando la forma de las partículas, lo que permite optimizarla con las energías de transición del material de banda intermedia. Como las nano-partículas metálicas (en adelante MNPs) deben ser inseridas en el material de la célula fotovoltaica, ellas deben cubrirse con una fina capa aislante para prevenir la recombinación electrón-hueco en su superficie.

A continuación se generaliza el análisis para calcular la dispersión de luz causada por esferoides de cualquier tamaño y material. Para ello, se usa un método analítico de separación de variables implementado en Mathematica7.0. Este código permite el estudio de las propiedades de dispersión de las partículas del tamaño de la longitud de onda (régimen mesoscópico), y se ha verificado que en este régimen esferoides dieléctricos se comportan mejor que metálicos. La intensidad de luz dispersada desde estos esferoides dieléctricos puede ser dos órdenes de magnitud mayor que la intensidad incidente, y la región focal frente a la partícula puede ser modificada de distintas maneras cambiando la geometría y/o material de la partícula.

Además, el trabajo experimental realizado en esta tesis ha permitido implementar en la práctica los conceptos estudiados para el análisis de MNPs con tamaños inferiores a la longitud de onda. Se ha desarrollado un método de deposición de partículas en solución coloidal que autogenera redes regulares de MNPs en la superficie de varios materiales como obleas de silicio, láminas de silicio amorfo, arseniuro de galio y vidrio.

(14)

Se ha realizado una serie de pruebas térmicas y químicas que muestra que procesos las nano-partículas pueden resistir para su inserción en un medio fotovoltaico. Las redes de MNPs se insertan después en un medio de silicio amorfo para estudiar el efecto de su campo cercano plasmónico en el incremento del espectro de absorción del material.

Las redes de MNPs construidas en este trabajo experimental han inspirado una nueva estrategia de fabricación de IBSCs usando puntos cuánticos coloidales (del inglés, CQDs). Estos CQDs pueden ser depositados en monocapas auto-ensambladas, usando procedimientos similares a los desarrollados para la deposición de MNPs coloidales. El uso de CQDs para formar la banda intermedia presenta, desde el punto de vista práctico y físico, varias ventajas importantes frente a los puntos convencionales crecidos epitaxialmente por el método de Stranski-Krastanov. Además, supone un método rápido y barato para construir redes binarias de QDs y MNPs, previstas en la parte teórica de esta tesis, en las que los MNPs actúan como antenas enfocando la luz en los puntos cuánticos y, por tanto, estimulando su absorción.
