Performance of the trigger system for displaced muons in CMS

Performance of the trigger system for displaced muons in CMS

ALEJANDRO SOTO RODRÍGUEZ (ON BEHALF OF THE CMS COLLABORATION)

FPU20/02225 funded by Grant PID2020-113341RB-100 funded by

Trigger and readout at the LHC experiments for Run 3 and beyond in Spain – COMCHA

20-22 March 2023

Introduction

• What are displaced muons?

• Muons that are not produced in the primary vertex (PV).

• They can be produced through the decay of a long- lived particle (LLP).

• Therefore, they do not have to point to the PV.

• Why are they interesting:

• Signature of new physics.

• Many exotic models can produce displaced muons:

• RPV, Exotic Higgs models, dark photon, …

• Challenges:

• They need a special reconstruction which doesn’t take into account the PV constrain.

• From the trigger perspective, this can explode the rate with fake tracks from pileup vertices.

• Highly displaced muons can be misidentified with low 𝑝_𝑇 non-displaced muons.

2

The CMS Muon Detector

Barrel Overlap

En dc ap

• Regarding L1 trigger, in this presentation I will focus on the overlap muon track finder (OMTF).

• The OMTF performs muon reconstruction in the overlap region.

• Challenges in the overlap region:

• Combines information from 3

subdetectors: DTs, RPCs and CSCs.

• Complicated geometry and difficult magnetic field.

• In each overlap area, the OMTF receives information from 15 layers.

Level 1 trigger OMTF

4

OMTF: Naïve-Bayes Classifier

• Reconstruction based on a Naïve-Bayes classifier:

• It performs muon identification and 𝑝_𝑇 measurement in one step.

• The foundation of the algorithm is the Bayes theorem.

• In this case:

𝑃 𝑝_𝑇 𝑥₁, … , 𝑥_𝐿 = 𝑃 𝑥₁, … , 𝑥_𝐿 𝑝_𝑇 𝑃(𝑝_𝑇) 𝑃(𝑥₁, … , 𝑥_𝐿)

• It is assumed that the log-likelihood that a muon has a given 𝑝_𝑇 𝑃(𝑝_𝑇|hits) is just a sum of the log-likelihoods of the muon hit 𝜙 positions in each detector layer 𝑃_{𝑙𝑎𝑦𝑒𝑟}(𝜙_𝑖^{𝑑𝑖𝑠𝑡}|𝑝_𝑇).

• 𝜙_𝑖^{𝑑𝑖𝑠𝑡} = Δ𝜙_𝑖 − Δ𝜙_𝑖^{𝑚𝑒𝑎𝑛}(𝑝_𝑇)

• Compare with precomputed patterns → pattern with the biggest likelihood gives the 𝑝_𝑇 estimation.

• The values of the log 𝑃_{𝑙𝑎𝑦𝑒𝑟}(𝜙_𝑖^{𝑑𝑖𝑠𝑡}|𝑝_𝑇) are stored in LUTs implemented in the FPGA BRAM modules.

OMTF: Run3 performance

6

• Efficiency evaluated with Run3 data of era E.

• Efficiency of the OMTF over 95% for 𝑝_𝑇 > 15 GeV.

• Good turn-on of the 𝑝_𝑇 curve.

OMTF: Phase-2 upgrade

• For the Phase-2 update of the CMS detector the DT trigger primitives are going to be updated.

• See Jaime’s presentation: link.

• A new set of patterns is trained with this new input.

• A slight gain in efficiency can be achieved for 𝜂 𝜖 (0.7, 0.9) which is the region where DTs are located.

Displaced OMTF

8

• A new approach is proposed to reconstruct displaced muons.

• The algorithm is modified to give two values for the muon 𝑝_𝑇: constrained and unconstrained to the interaction point.

• Same patterns are used for prompt and displaced muons.

• An extrapolation is performed using 𝜙_𝑟𝑒𝑓^𝑏 .

• 𝜙_𝑖^{𝑑𝑖𝑠𝑡} = 𝜙_𝑖^𝑏 − 𝜙_𝑟𝑒𝑓^𝑏 − Δ𝜙_𝑖 − Δ𝜙_𝑖^{𝑚𝑒𝑎𝑛} 𝑝_𝑇 ; if layer 𝑖 has bending measurement.

• 𝜙_𝑖^{𝑑𝑖𝑠𝑡} = Δ𝜙_𝑖 − Δ𝜙_𝑖^extrpol − Δ𝜙_𝑖^{𝑚𝑒𝑎𝑛}(𝑝_𝑇); if layer 𝑖 does not have bending measurement.

• Only MB1 and MB2 are used in the extrapolation.

Displaced OMTF: performance

• Highly displaced muons are reconstructed as low 𝑝_𝑇 muons.

• Using 𝑢𝑝_𝑇 allow us to trigger on highly displaced muons.

• Efficiency of ~50 % for 𝑑_𝑥𝑦 𝜖[0, 100] cm.

Displaced OMTF: performance

10

• Rate of ~2kHz for a 𝑝_𝑇 threshold of 20 GeV.

• Additional rate of +1kHz if we allow displaced muons with a 𝑢𝑝_𝑇 threshold of 20 GeV.

Additional rates

High Level

Trigger

Displaced global reconstruction at HLT

• CMS has three types of muons:

• Standalone muons: reconstructed using only information from the muon chambers.

• Global muons: reconstructed using information from the tracker and segments from the muon chambers.

• Tracker muons: tracker tracks that are matched to muon segments.

• Global muons have better resolution than muons reconstructed only in the chambers.

• We have developed a new displaced global reconstruction (dGbl+dTks) that incorporates:

• Improved seeding that targets displaced signatures.

• Final estimate of the muon momentum based on the global track fit.

• Displaced tracker muons (dTks).

12

Tracker track

Muon segments

Efficiencies for displaced muons

𝐿_𝑥𝑦 = 𝑣_𝑥 − 𝑏_𝑥 ² + 𝑣_𝑦 − 𝑏_𝑦 ² ቊ𝑣: muon vertex 𝑏: beam spot

• Here we compare the efficiency of our proposal dGbl+dTks and the up to now reconstructions used in CMS:

• Standard iterative reconstruction.

• Cascade reconstruction.

• Very good improvement in efficiency and momentum resolution 𝜎_𝑝.

Rate of the displaced paths

• Two double muon paths are built using the cascade and dGbl+dTks reconstructions.

• To reduce the rate, muons with low displacement are vetoed (𝑑_𝑥𝑦 < 0.01 cm).

• Less rate of the new proposal thanks to the better 𝑑_𝑥𝑦 resolution.

14

Trigger path Total rate (Hz) Total timing (ms)

HLT_DoubleL3Mu16_10NoVtx_DxyMin0p01cm_v1 (cascade reco) 16.7 5.9 HLT_DoubleL3dTkMu16_10NoVtx_DxyMin0p01cm_v1 (dGbl+dTks) 14.7 4.9

HLT_DoubleL3dTkMu16_10NoVtx_DxyMin0p01cm_v1 HLT_DoubleL3Mu16_10NoVtx_DxyMin0p01cm_v1

Rate vs PU

Rate measured with real data.

Displaced standalone reconstruction at HLT

• The performance of the standalone reconstruction is evaluated using cosmics recorded during Run3.

• Two paths are studied:

• Standalone collision seeded: HLT_L2Mu10NoVtx_v1.

• Standalone cosmic seeded: HLT_L2Mu10NoVtx_CosmicSeed_v1.

• Good performance of both paths is observed.

Summary

• The performance and capabilities of the CMS trigger system for reconstructing displaced muons has been presented.

• The overlap muon track finder has been adapted to trigger on displaced muons with an efficiency of ~50% for medium displaced muons.

• This comes with a moderate increase in rate.

• Currently working on deploying online the displaced OMTF for the 2023 data taking.

• From the HLT side, a new displaced global muon reconstruction has been developed.

• It offers a moderate gain in efficiency but a good reduction in rate and timing.

• An HLT path using the new displaced reconstruction has been used during 2022 data taking with excellent performance.

16

Thanks for your attention!

18

Backup

The CMS L1 Trigger

Muon Track Finders:

Combines local info from different stations to find the trajectory and

estimate momentum.

Local reconstruction:

Local information, reconstructs segment

direction in each station →

(TPs).

Global Trigger:

Combine Muon and Calo trigger into a single

decision.
